- Page 1 Cameras HD-TVI User Manual TVI21.18(V1.0) TBK-MD5431EIR/ TBK-MD5631EIR / TBK-MD5831EIR/ TBK-BUL4431EIR / TBK-BUL4831EIR...
-
Page 2: Table Of Contents
TBK HD TVI Camera Series Contents Notes ..................2 Product Introduction ............3 Production Instruction ........3 Product Feature ............. 4 Product Structure ............. 4 Technical Parameters ............. 6 Menu Instruction ............10 Camera Menu Setting ........11 Product Installation ............15 Note ................. -
Page 3: Notes
TBK HD TVI Camera Series Notes Read this manual carefully before use. 1)To reduce the risk of electric shock, do not open the machine and maintain by yourself, please consult a professional service person. 2)To prevent fire or shock hazard, use the power after safety certification, the input voltage, current, voltage polarity and operating temperature must meet the requirements of this camera. -
Page 4: Product Introduction
8)The camera cannot be placed near the radiator or heating resistor. Product Introduction 2.1 Production Instruction This manual is applicable to following models: 720p resolution camera:TBK-MD5431EIR,TBK-BUL4431EIR 1080p resolution camera: TBK-MD5631EIR, TBK-MD5831EIR, TBK-BUL4831EIR. This series of cameras are adopted CMOS image sensor with high performance, which provides mega pixel resolution and supports HD video. -
Page 5: Product Feature
TBK HD TVI Camera Series 2.2 Product Feature ● Coaxial cable adopted，BNC connector as cable standard。 HD TVI/CVBS dual output ● Auto Day/Night（ICR） ● Auto Defog ● WDR, 2D/3D NR ● 8X Digital Zooming ● Motion Detection, Privacy Mask ● Auto Iris（Specific models） ●... - Page 6 TBK HD TVI Camera Series Photo 3-2 TBK-MD5431EIR and TBK-MD5831EIR Photo 3-3 TBK-MD5631EIR www.tbkvision.com...
-
Page 7: Technical Parameters
TBK HD TVI Camera Series Technical Parameters Model TBK-MD5431EIR Image Sensor 1/3” 1.3MP SONY Exmor CMOS Image Effective Pixels 1305(H)×1049(V) Digital: 1280×720P Resolution Analog:960H S/N Ratio ≥50dB (AGC Off) Min. Illumination 0.01Lux@F2.0 (0Lux IR On) Scanning System Progressive Digital: HD-TVI (720P) Video Output Analog:1Vp-p75Ω/BNC... - Page 8 TBK HD TVI Camera Series Lens 2.8-12mm Auto Focus IR Range General specification Input Voltage DC12V±10% Operation Temp. -10℃~+50℃(14℉~122℉) Current 410mA Power Consumption ＜6W Weight 630g IP Rating IP66 Operation humidity ＜85%RH (Non-condensation) Model TBK-MD5631EIR TBK-MD5831EIR Image Sensor 1 /2.8” 2MP SONY Exmor CMOS Image Effective Pixels 1984(H)×1105(V)
- Page 9 TBK HD TVI Camera Series White Balance Auto Defog OFF/ON 2D+3D NR OFF/LOW/MIDDLE/HIGH Privacy Mask ON/OFF (16 Areas) Motion Detection ON/OFF (4 Areas) ZOOM IN 1X-8X Lens 3.6mm 2.8-12mm Auto Focus 2pcs IR Array IR LED 3pcs IR Array LEDS LEDS IR Range General specification...
- Page 10 TBK HD TVI Camera Series Model TBK-BUL4431EIR TBK-BUL4831EIR 1 /3” 1.3MP SONY 1 /2.8” 2MP SONY Image Sensor Exmor CMOS Exmor CMOS Image Effective Pixels 1305(H)x1049(V) 1984(H)×1105(V) Digital:1920x1080p, Digital:1280×720 Resolution 1280×720p p Analog:960H Analog:960H S/N Ratio ≥50dB (AGC Off) Min. Illumination 0.01Lux@F2.0 (0Lux IR On) Scanning System Progressive...
-
Page 11: Menu Instruction
TBK HD TVI Camera Series IR Range General specification Input Voltage DC12V±10% Current 370mA Power <4.5W Consumption Weight 760g IP Rating IP66 Operation Temp. -10℃~+50℃(14℉~122℉) Operation ＜85%RH (Non-condensation) humidity Menu Instruction Press "MENU" button to enter the main MENU, press "UP" and "DOWN"... -
Page 12: Camera Menu Setting
TBK HD TVI Camera Series 5.1 Camera Menu Setting MAIN MENU EXPOSSURE DAY&NIGHT www.tbkvision.com... - Page 13 TBK HD TVI Camera Series IMAGE SPECIAL SPECIAL-SYSTEM 1080P 720P www.tbkvision.com...
- Page 14 TBK HD TVI Camera Series SPECIAL-COMM ADJ SPECIAL-PRIVACY www.tbkvision.com...
- Page 15 TBK HD TVI Camera Series SPECIAL-MOTION SPECIAL-SHADING SPECIAL-ADJUST www.tbkvision.com...
-
Page 16: Product Installation
TBK HD TVI Camera Series Product Installation 6.1 Note 1) Make sure the unit is powered off before installation. 2) Check power supply voltage consistent with the electric voltage to prevent voltage unworthy, resulting in damage to the device. 3) Do not use in the environment beyond the boundaries of the temperature, and maintain good ventilation to prevent the rain in order to reduce the risk of fire or electric shock. -
Page 17: Installation Method
TBK HD TVI Camera Series 6.3 Installation Method 1. Check the equipment whether it is damaged. 2. Mounting bracket or base. ① If the cement wall, install the expansion screws (expansion screw holes need stand or base hole), and then mount bracket or base. -
Page 18: Connection
TBK HD TVI Camera Series and camera. 6.4 Connection Connection as show in the figure below Camera connectors BNC Green connector: TVI digital video signal BNC Yellow connector: PAL Analogue video signal RCA Red connector: power supply www.tbkvision.com... - Page 19 TBK HD TVI Camera Series Appendix: FAQ Q: No picture with power on A: It may result from abnormal power supply. Please check if the power supply voltage and its polarity are correct. Besides, please confirm if wires connection and monitors are normal. Q: Unclear image output A: It is caused by incomplete adjustment of the lens back focus.
- Page 20 www.tbkvision.com...
