  • Page 1 HD-TVI Cameras HD-TVI 1080P User Manual v2 TBK-MD5531EIR, TBK-MD5731EIR, TBK-BUL4531EIR, TBK-BUL4731EIR...

  • Page 2: Product Description

    TBK HD TVI Camera Series manual V2 Product description 1.1 Product Introduction This manual is applicable to following models: TBK-MD5531EIR, TBK-MD5731EIR, TBK-BUL4531EIR, TBK-BUL4731EIR. This series of cameras use 2MP sensor, to provide HD-TVI video signal at 1080P resolution. These are TVI cameras,...

  • Page 3: Product Structure

    TBK HD TVI Camera Series manual V2  High Definition TVI 1080P real-time video.  HD TVI video output, no delay, lossless, long distance transmission.  Progressive scan CMOS,capture moving object perfectly.  Reach 400 meters coaxial cable real-time transmission. ...
  • Page 4 TBK HD TVI Camera Series manual V2 Photo 2-1 TBK-MD5531EIR Photo 2-2 TBK-MD5731EIR www.tbkvision.com...
  • Page 5 TBK HD TVI Camera Series manual V2 Photo 2-3 TBK-BUL4531EIR Photo 2-4 TBK-BUL4731EIR www.tbkvision.com...

  • Page 6: Technical Parameters

    1/2,7" color CMOS（1080P/2MP） Image Sensor Signal HD-TVI Resolution 1080P 25IPS 0.1 lux F1.2（0 lux with IR LED ON） Minimum Illumination Lens TBK-MD5531EIR: 3,6 mm TBK-MD5731EIR: 2,8-12 mm TBK-BUL4531EIR: 3.6mm TBK-BUL4731EIR: 2,8-12 mm Video Output BNC×1 D&N Support ICR >52dB（AGC off）...
  • Page 7 Shutter, AGC, mirror, flip LEDS IR TBK-MD5531EIR: 24 pcs TBK-MD5731EIR:36 pcs TBK-BUL4531EIR: 36 pcs TBK-BUL4731EIR: 42 pcs Protection level IP65 Power supply TBK-MD5531EIR: 12 VDC 400 mA TBK-MD5731EIR: 12VDC 500 mA TBK-BUL4531EIR: 12VDC 500 mA TBK-BUL4731EIR: 12VDC 600 mA www.tbkvision.com...

  • Page 8: Product Installation

    TBK HD TVI Camera Series manual V2 Product Installation Avoid installing the camera directly towards the sun. Do not install it in the place where temperature is above 50℃ or below -20℃. No installation in the areas with frequent vibration. Avoid operating and storing in the water.

  • Page 9: Troubleshooting

    TBK HD TVI Camera Series manual V2 Troubleshooting Problem Reason How to solve Image normal in the day Power is not Change power while vague or enough or supply or being power cable is shorten power interfered by too long. cable.
  • Page 10 www.tbkvision.com...
