TBK vision TBK-M71HF Instruction Manual

Mini/medium dome ccd camera
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
2003/12/24 Ver:0.1 No:040024/1
Mini/Medium DOME CCD CAMERA
I N S T R U C T I O N
M A N U A L
CONTENTS
1. DESCRIPTION ................... 1
2. INSTALLATION .................. 2
3. WIRING INSTRUCTIONS .. 3
1. DESCRIPTION
Thank you very much for purchasing our product.
This B/W (COLOR) Mini/Medium DOME CCD/ CMOS Camera uses high
sensitive 1/3"(1/4") interline transfer CCD, and all state circuitry which
provides long life and high reliability. This Camera offers excellent image
quality with low lag and high burn resistance, and is not subject to
distortions from magnetic fields. Highly resistance to shock and vibration,
and easy to install, this Camera is a very good choice for your B/W
(COLOR) CCTV system.
Page
4. SPECIFICATIONS .............. 4
P.1
(18)
Page

Advertisement

loading
Need help?

Need help?

Do you have a question about the TBK-M71HF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TBK vision TBK-M71HF

Summary of Contents for TBK vision TBK-M71HF

  • Page 1 2003/12/24 Ver:0.1 No:040024/1 Mini/Medium DOME CCD CAMERA I N S T R U C T I O N M A N U A L (18) CONTENTS Page Page 1. DESCRIPTION ....1 4. SPECIFICATIONS ....4 2. INSTALLATION ....2 3.

  • Page 2: Installation

    2. INSTALLATION STEP 1: Remove the Dome Cover. STEP 2:Secure Dome Camera in the desired ceiling position with the 3 screws as shown in Figure 1. STEP 3: The vertical angle can be adjusted by loosening the 2 screws as shown in Figure 2 and by turning the Camera Case vertically.

  • Page 3: Wiring Instructions

    STEP 5: Place the Dome Cover over the Camera and tighten it by turning it to the right. Installation is finished. 3. WIRING INSTRUCTIONS STEP 1:Connect the coaxial cable between the camera and the monitor using 75 Ohm coaxial cable. STEP 2: Insert the AC plug into the AC socket and the DC plug to the DC Jack.

  • Page 4: Specifications

    4. SPECIFICATIONS Color 1/3” CCD Color 1/3” CCD Color 1/4” CCD Model Type. High Resolution Normal Resolution Normal Resolution Image Pick-up SONY 1/3” Super SONY 1/3” Super SHARP 1/3” CCD SONY 1/4” CCD Device HAD CCD sensor HAD CCD sensor sensor sensor Effective Picture...
  • Page 5 B/W Analog Type Model Type. B/W 1/3” CCD High Resolution B/W 1/3” CCD Normal Resolution SONY 1/3” Super HAD SAMSUNG 1/3” CCD Image Pick-up Device SONY 1/3” Super HAD CCD sensor CCD sensor sensor Effective Picture EIA: 768×494 EIA: 510×492 Elements (H×V) CCIR: 752×582 CCIR: 500×582...
  • Page 6 Color 1/3” CMOS B/W 1/4” CMOS Model Type. Normal Resolution Normal Resolution Image Pick-up Omni Vision 1/3” CMOS sensor Omni Vision 1/4” CMOS sensor Device Effective Picture NTSC: 510×492 EIA: 320×240 Elements (H×V) PAL: 500×582 CCIR: 352×288 Horizontal 330 horizontal TV lines 240 horizontal TV lines Resolution Minimum...
