2005/05/20 Ver:1.0 No:040024G/1 Medium Vari-Focal Dome CCD Camera I N S T R U C T I O N M A N U A L CONTENTS Page Page 1. DESCRIPTION ....... 0 4. SPECIFICATIONS ....6 2. INSTALLATION ..... 1 3.
Page 2
2. INSTALLATION STEP 1: Remove the Dome Cover. STEP 2: Secure Dome Camera in the desired ceiling position with the 4 screws as shown in Figure 1. STEP 3: The vertical angle can be adjusted by loosening the 2 screws as shown in Figure 2 and by turning the Camera Case vertically.
STEP 5: Place the Dome Cover over the Camera and tighten it by turning it to the right. Installation is finished. 3. HOW TO OPERATE (1) Connect the Video Output to the monitor or other video device through a 75 Ohms type coaxial cable. (2) Connect the power source , insert the AC plug into the AC socket and the DC plug to the DC Jack (+12V DC in jack center).
Page 4
TELE WIDE Focal Adjustment FL: Flicker Lens ON/OFF AGC: Auto Gain Control High/Low AES: Auto Electronic Shutter ON/OFF BLC: Back Light Compensation ON/OFF VR Adjustment level for DC Drive Lens Inside Control Board (For Color) AES: Auto Electronic Shutter ON/OFF BLC: Back Light Compensation ON/OFF VR Adjustment level for DC Drive Lens Inside Control Board (For B/W)
Page 5
VR Adjustment level for DC Drive Lens Inside Control Board (For Color Hi-Resolution) (3) Once the picture appears on the monitor, open the cover adjust the lens’ wrench of “TELE← → WIDE” to get the view angle that you desire, then adjust the focus wrench of the Lens to obtain the best picture.
4. SPECIFICATIONS SONY 1/3” CL SONY 1/3” B/W SONY 1/3” B/W SONY 1/3” CL Image Device Super HAD Super HAD Hi-Res. Super HAD Hi-Res. Super HAD NTSC: 510×492 EIA: 510×492 EIA: 768×494 NTSC: 768×494 Picture Elements PAL: 500×582 CCIR: 500×582 CCIR: 752×582 PAL: 752×582 380 TVL...
