TBK vision TBK-MD5641EIR User Manual

4 in 1
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cameras 4 in 1
User Manual
TBK-MD5641EIR
TBK-MD5841EIR/
TBK-BUL4841EIR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TBK-MD5641EIR and is the answer not in the manual?

Questions and answers

Related Manuals for TBK vision TBK-MD5641EIR

Summary of Contents for TBK vision TBK-MD5641EIR

  • Page 1 Cameras 4 in 1 User Manual TBK-MD5641EIR TBK-MD5841EIR/ TBK-BUL4841EIR...

  • Page 2: Table Of Contents

    TBK Camera 4 in 1 Contents Notes .................2 Product Introduction ............3 Production Instruction .........3 Product Feature ..........4 Product Structure ............4 Technical Parameters ............6 Product Installation ............9 Note ..............9 Installation Tools and Information ......9 Installation Method ........... 10 Connection ............11 Menu Instruction ............

  • Page 3: Notes

    TBK Camera 4 in 1 Notes Read this manual carefully before use. 1)To reduce the risk of electric shock, do not open the machine and maintain by yourself, please consult a professional service person. 2)To prevent fire or shock hazard, use the power after safety certification, the input voltage, current, voltage polarity and operating temperature must meet the requirements of this camera.

  • Page 4: Product Introduction

    8)The camera cannot be placed near the radiator or heating resistor. Product Introduction 2.1 Production Instruction This manual is applicable to following models: 1080p resolution camera: TBK-MD5641EIR, TBK-MD5841EIR, TBK-BUL4841EIR. This series of cameras are adopted CMOS image sensor with high performance, which provides mega pixel resolution and supports HD video.

  • Page 5: Product Feature

    TBK Camera 4 in 1 2.2 Product Feature ● Coaxial cable adopted，BNC connector as cable standard. Dual output: HD signal switcheable to TVI/CV/AHD and CVBS signal. ● Auto Day/Night（ICR） ● Auto Defog ● WDR, 2D/3D NR ● Motion Detection, Privacy Mask ●...
  • Page 6 TBK Camera 4 in 1 Photo 3-2 TBK-MD5841EIR Photo 3-3 TBK-MD5641EIR www.tbkvision.com...

  • Page 7: Technical Parameters

    TBK Camera 4 in 1 Technical Parameters Model TBK-MD5641EIR TBK-MD5841EIR Image Sensor 1 /2.7” 2.1MP SONY Exmor CMOS Image Effective Pixels 1928(H)×1088(V) Digital:1920x1080p 25ips Resolution Analog:700LTV S/N Ratio ≥41dB (AGC Off) Color: 0.1Lux@F2.0 AGCE ON Min. Illumination B / N:0.001Lux@F2.0 AGC ON...
  • Page 8 TBK Camera 4 in 1 Lens 3.6mm 2.8-12mm Auto Focus IR LED 3pcs IR Array LEDS IR Range General specification Input Voltage DC12V±10% Current 300mA 410mA Power <4.5W <6W Consumption Weight 240g 630g IP Rating IP66 Operation Temp. -10℃~+50℃(14℉~122℉) Operation ＜85%RH (Non-condensation) humidity Model...
  • Page 9 TBK Camera 4 in 1 Day & Night EXTERN,COLOR, B&W, AUTO White Balance Auto Defog OFF/ON 2D+3D NR OFF/LOW/MIDDLE/HIGH Privacy Mask ON/OFF (16 Areas) Motion Detection ON/OFF (4 Areas) ZOOM IN 1X-8X Lens 2.8-12mm Auto Focus IR LED 24pcs IR LEDS IR Range General specification Input Voltage...

  • Page 10: Product Installation

    TBK Camera 4 in 1 Product Installation 5.1 Note 1) Make sure the unit is powered off before installation. 2) Check power supply voltage consistent with the electric voltage to prevent voltage unworthy, resulting in damage to the device. 3) Do not use in the environment beyond the boundaries of the temperature, and maintain good ventilation to prevent the rain in order to reduce the risk of fire or electric shock.

  • Page 11: Installation Method

    TBK Camera 4 in 1 5.3 Installation Method 1. Check the equipment whether it is damaged. 2. Mounting bracket or base. ① If the cement wall, install the expansion screws (expansion screw holes need stand or base hole), and then mount bracket or base.

  • Page 12: Connection

    TBK Camera 4 in 1 5.4 Connection Connection as show in the figure below 5.4.1 Camera connectors BNC Green connector: switchable TVI/CVI/AHD HD video signal. BNC Yellow connector: PAL Analogue video signal RCA Red connector: power supply 12 DCV www.tbkvision.com...
  • Page 13 TBK Camera 4 in 1 5.4.2 How to select HD video output Analogue video signal and HD video signal are simultaneous. HD signal (green connector) is switchable between three HD technologies: TVI or CVI or AHD. In order to select each HD signal please use the joystick attached at the camera wire and follow this two steps: Image: Camera wire attached joystick Firstly:, hold the central botton (menu botton) during 5 sec.
  • Page 14 TBK Camera 4 in 1 Menu with TVI signal selection: Menu with CVI signal selection: Menu with AHD signal selection: www.tbkvision.com...

  • Page 15: Menu Instruction

    TBK Camera 4 in 1 Menu Instruction To enter menu from analogue video output use joystick atacched on the camera wire.Press "MENU" button to enter the main MENU, press "UP" and "DOWN" arows in order to select menus, press "LEFT" and "RIGHT" choice or set the corresponding function, to enter submenu please press "MENU"...

  • Page 16: Camera Menu Setting

    TBK Camera 4 in 1 6.1 Camera Menu Setting MAIN MENU LENS, select between iris control (ELC, ALC) ELC, electronic iris control. (NORMAL, DEBLUR) ALC, automatic iris control . INDOOR / OUTDOOR /DEBLUR *DEBLUR improve blur pictures caused by quick mouvements.
  • Page 17 TBK Camera 4 in 1 WHITE BAL, alows to adjust white balance. Options: AUTO, AUTO Ext, PRESET, MANUAL. MANUAL (KELVIN, R-GAIN, B-GAIN) KELVIN set color temperature (MIDDLE,HIGH, LOW) R-GAIN to set red color gain. Range 0~20 R-BLUE to set blue color gain. Range 0~20 BACKLIGHT, options OFF, BLC, HLC, WDR.
  • Page 18 TBK Camera 4 in 1 DAY&NIGHT Menú MODE: select between working mode (AUTO, COLOR, B&W, EXTERN) IMAGE SHARPNESS, range 0~10 FREEZE, allows freezing image (OFF/ON) FLIP, allows the image to turn up and to turn downn (OFF, H-INV, V-INV, HV-INV). ACE, contrast adaptative settings.
  • Page 19 TBK Camera 4 in 1 SPECIAL SPECIAL-SYSTEM OUTPUT MODE, shows unit resolution:1080p. FRAME RATE, shows 25FPS( for PAL system) or 30FPS (for NTSC system). CVBS, analogue video output estándar (PAL/NTSC). By default PAL. BLACK LEVEL, black color level. (FULL, COMP, USER) VERSION, shows camera firmware version.
  • Page 20 TBK Camera 4 in 1 SPECIAL-PRIVACY menu for setting privacy masks, 16 areas avalilabe ZONE NUM, select the mask to set (0~15) ZONE DISP, activate /desactivate the mask (ON/OFF) H-POS, V-POS, to set mask posistion on screen H-SIZE, V-SIZE, to set size mask. Y-LEVEL, CR-LEVEL, CB-LEVEL, to set mask color.
  • Page 21 TBK Camera 4 in 1 SENSITIVITY, to set motion detection sensitivity. (Range 0~20) WINDOW TONE, stand out detection area with background. WINDOW USE, to select one area between 4 available. (Range 0~3) WINDOW ZONE, to choose if are is visble or not. (OFF/ON).

  • Page 22: Appendix: Faq

    TBK Camera 4 in 1 Appendix: FAQ Q: No picture with power on A1: It may result for a wrong HD video signal selection, DVR and camera must have the same HD video technology. Different HD video technologies are incompatible between them. Go to 5.4.2 How to select HD video output in order to select the right HD technology.
  • Page 23 TBK Camera 4 in 1 A: This phenomenon is caused by color scrolling, which is mainly due to alternating electromagnetic field of fluorescent lamp, and the inherent phenomenon of camera. It can be weakened with two methods: one is to reduce the usage of fluorescent lamp. The other is to enlarge the distance with the camera.
  • Page 24 www.tbkvision.com...

This manual is also suitable for:

Tbk-md5841eirTbk-bul4841eir
