2003/12/19 Ver:1.0 No:040025A
HIDDEN CCD CAMERA
I N S T R U C T I O N
M A N U A L
CONTENTS
1. Description ............................... 1
2. Installation ................................ 2
3. Wiring instructions ................... 3
4. Specifications ........................... 4
Thank you very much for purchasing our product.
This B/W (COLOR) HIDDEN CCD Camera uses high sensitive 1/3" (1/4")
interline transfer CCD Image Sensor (CCD = Charge Coupled Device), and all
state circuitry which provides extremely long life and high reliability. This
Camera offers excellent image quality with low lag and high burn resistance,
and is not subject to distortions from magnetic fields. Highly resistance to
shock and vibration, and easy to
choice for your B/W (COLOR) CCTV
Page
and descriptions ........................ 5
install this Camera is a very good
P.1
system.
19
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TBK-H24HF and is the answer not in the manual?

Questions and answers

Related Manuals for TBK vision TBK-H24HF

Summary of Contents for TBK vision TBK-H24HF

  • Page 1: Table Of Contents

    2003/12/19 Ver:1.0 No:040025A HIDDEN CCD CAMERA I N S T R U C T I O N M A N U A L CONTENTS Page Page 1. Description ....... 1 5. PIR Detector board installation 2. Installation ........ 2 and descriptions ......5 3.

  • Page 2: Installation

    2. Installation STEP 1: Secure the bracket to the wall with screws. ( included as shown in Figure 1 ) STEP 2: Attach the Camera Case to the bracket as shown in Figure 2.

  • Page 3: Wiring Instructions

    STEP 3: Adjust the vertical and horizontal angles by loosening screws (A&B) as in Figure 3 and by turning the bracket vertically and horizontally. 3. Wiring instructions STEP 1:Connect the coaxial cable between the camera and the monitor using a 75Ohm coaxial cable. STEP 2: Insert the AC plug into the AC power socket and the DC plug to the DC Jack.

  • Page 4: Specifications

    4. Specifications CL Normal CL Normal CL High Model B/W Normal Resolution Resolution Resolution Resolution SAMSUNG SONY 1/3” SONY 1/3” SONY 1/4” SONY 1/3” Image Pick-up 1/3” CCD Super HAD Super HAD Super HAD Super HAD Device sensor CCD sensor CCD sensor CCD sensor CCD sensor...

  • Page 5: Description

    5. PIR Detector board installation and descriptions (for model including PIR working sensor only) 6 Output Terminals N.O. - + N.C. PULSE Pulse Count Led Selector Light Control Recording Control Time Adjustment Sensitivity Adjustment Options Description 1.LED Selector: A. Top + Center w/black cap: Upon Walk-testing: Light blinking (Disadvantages: Easy to identify as a security system.) B.
  • Page 6 Options Description 4.Alarm control, Light control or A. Top + Center w/black cap: Operate with “VR2” to adjust Recording control time. (To set the relay output of the Light control or (N.O or N.C) Recording control, the time is selected by individual preference or application.
