MultiMobile USB ™ V.92 Portable USB Modem MT9234MUCDC User Guide Downloaded from Elcodis.com electronic components distributor...
Page 2
Fax: 763‐785‐9874 www.multitech.com Contacting Multi‐Tech Support Online Support Portal: https://support.multitech.com In order to better serve our customers, manage support requests and shorten resolution times, we have created the online web portal allowing you to submit questions regarding Multi‐Tech products directly to our technical support team. Get answers to your most complex questions, ranging from implementation, troubleshooting, product configuration, firmware upgrades and much more. To create an account and submit a Support Case on the Portal, visit https://support.multitech.com. Knowledge Base and Support Services: www.multitech.com/support.go The Knowledge Base provides immediate answers to your questions and gives you access to support resolutions for all Multi‐Tech products. Visit our support area on the website for other support services. Technical Support U.S. office hours are 9am – 5pm, CST Country By Email By Phone Europe, Middle East, Africa: support@multitech.co.uk (44) 118 959 7774 U.S., Canada, all others: support@multitech.com (800) 972‐2439 or (763) 717‐5863 Warranty Warranty information can be found at: http://www.multitech.com/warranty.go Downloaded from Elcodis.com electronic components distributor...
Table of Contents Contents – ...................... 4 HAPTER RODUCT ESCRIPTION Introduction ............................ 4 Features ............................ 4 Telecom Safety Warnings ........................ 4 Shipping Package Contents ...................... 5 About AT Commands ........................ 5 Technical Specifications ........................ 5 – ........................ 6 HAPTER NSTALLATION Install the Modem Driver ........................ 6 Windows Installer .......................... 6 Manually installing the modem in Windows 7 ................ 8 Installing the Modem in Windows Vista .................. 12 Installing the Modem in Windows XP and Server 2003 or 2008 ........... 16 Configuring the Modem for Your Country .................. 20 Using the Global Wizard Utility to Configure Country Code .......... 20 Using AT Commands to Configure Country Code ............. 20 – ........................ 21 ...
Chapter 1 – Product Description Chapter 1 – Product Description Introduction The MultiMobile USB V.92 Portable USB modem MT9234MU‐CDC provides V.92/56K data rates, fax and file transfer capabilities and a hot‐swappable USB interface. This modem, weighing only 2 ounces, is ideal for mobile users who want email and Internet access on the road. The MT9234MU‐CDC modem can also serve as the mobile user’s home office desktop modem. This user’s guide will help you install, configure, test and use your modem. Features Command Buffer 40 characters Diagnostics Power‐on self test, local analog & local digital loop, remote digital loop. LED Indicators LEDs for Data, Carrier Detect, Off Hook, Terminal Ready Intelligent Features Fully AT command compatible; autodial, redial, repeat dial; pulse or tone dial; dial pauses; auto answer; caller ID; EIA extended automode; adaptive line probing; automatic symbol and carrier frequency during start‐up, retrain, and rate renegotiation; call status display, auto‐parity and data rate selections; keyboard‐ controlled modem options; non‐volatile memory; on‐screen displays for modem option parameters; command lines of up to 40 characters each; help menus; remote configuration. Telecom Safety Warnings • Never install telephone wiring during a lightning storm. • Never install a telephone jack in wet locations unless the jack is specifically designed for wet locations. • This product is to be used with UL and cUL listed computers. • Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. •...
Chapter 1 – Product Description Shipping Package Contents • MT9234MU‐CDC modem • One RJ‐11 cable • One MultiMobile USB CD Inspect the contents for signs of any shipping damage. If damage is observed, do not power up (connect to a USB port) the unit. Contact Multi‐Tech’s Technical Support for advice (see page 2). About AT Commands AT Commands for this product are published in a separate document and included on the MT9234MU‐ CDC CD that accompanies your modem. Technical Specifications Trade Name MultiMobile™ USB Model Number MT9234MU Data Rates 56K download speeds from digital V.92/V.90 servers; 33.6K upload and download speeds from non‐V.92/V.90 servers and other client modems 33.6K and below Fax Rates Standards: V.92, V.90 enhanced, V.34 and below Data V.42 Error Correction Data Compression V.44, V.42bis, MNP Class 5 Fax V.34, Class 2.1 & 1.0, V.17, Group 3; Class 1 & 2, Error Correction Mode Video V.80 Cables 1 USB series A 1 RJ‐11 Operation USB Port: 12 Mbps ...
Chapter 2 ‐ Installation Chapter 2 – Installation Install the Modem Driver Windows Installer Your product CD contains an installer program for current Windows operating systems (Windows XP and newer only) that should be used before plugging in your USB modem. Should you happen to connect your USB modem before using the installer program, please follow the directions in the following sections for your particular version of Windows. Insert the product CD into a compatible drive. Do not connect your modem yet. Click on the Preinstall Windows Drivers button from the main splash screen of the CD. Click the button that matches your operating system [32‐bit or 64‐bit]. You can see what type of system you are using from the Control Panel | System screen. Windows may pop‐up a User Account Control window. Select the YES button to continue with the driver installation. Click on the next button to start the driver pre‐installation. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 7
Chapter 2 ‐ Installation There will be a transitory screen, then the process will complete. Click on the Finish button. Connect your USB modem to an available port and Windows will detect and install the modem. Your installation is complete. After the installation has been completed, you should test the operation of your new MT9234MU by registering it. Key in the URL given below and follow the on‐line instructions: http://www.multitech.com/en_US/TOOLS/Forms/register/warranty.asp Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 7 Downloaded from Elcodis.com electronic components distributor...
Chapter 2 ‐ Installation Manually installing the modem in Windows 7 If you did not use the pre‐installer for Windows, this is the process for installing your modem. After connecting your MT9234MU‐CDC to an available USB port, Windows 7 will report that the driver software was not successfully installed; Windows 7 no longer uses the new device wizard for installations. Pointing Windows 7 to the drivers needed is a simple process as shown below. Insert your MT9234MU‐CDC product CD into an available drive. You can ignore or close the CD Start Menu for now. Click the Windows Start button and select Control Panel from the options in the right‐hand pane. Left‐click the Hardware and Sound link. In the Devices and Printers section at the top, click the Device Manager link at the end. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 9
Chapter 2 ‐ Installation In the list of devices, you will see an item called MT9234MU‐CDC. Right‐click on this item and select Update Driver Software. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 9 Downloaded from Elcodis.com electronic components distributor...
Page 10
Chapter 2 ‐ Installation Choose the second option “Browse my computer for driver software” and left‐click on it. Click on the Browse button and navigate to the drive containing the MT9234MU‐CDC CD and double click to open that. Select the folder containing the appropriate drivers for your install (either 34‐bit or 64‐bit) and click OK. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 11
Chapter 2 ‐ Installation Click the Next button at the bottom of the Update Driver Software window to continue the installation. At this point you may see a Windows Security window stating that the publisher cannot be verified – click Install this driver software anyway. There will be a transitory screen as the installation completes. Click Close on the last screen to complete the installation. Your modem is now installed and ready to use. After the installation has been completed, you should test the operation of your new MT9234MU by registering it. Key in the URL given below and follow the on‐line instructions: http://www.multitech.com/en_US/TOOLS/Forms/register/warranty.asp Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 11 Downloaded from Elcodis.com electronic components distributor...
Chapter 2 ‐ Installation Installing the Modem in Windows Vista If you did not use the pre‐installer for Windows, this is the process for installing your modem. Power up your computer. If you have not already done so, connect the modem’s USB cable to a USB port on the computer and connect the phone line between the modem and a telephone wall jack. Windows will detect that the new modem is present and start the New Hardware wizard. Select the ‘Locate and install driver software (recommended)’ option. Note: Throughout the installation, you may be prompted by the Vista ‘User Account Control’ (hereafter referred to as the UAC). When prompted, please click the Continue button to proceed with the installation. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 13
Chapter 2 ‐ Installation The New Hardware wizard will now ask if you want to search online for drivers, select ‘Don’t search online.’ Windows will now direct you to insert the disc that came with your device – if you have not already done so, put the MT9234MU‐CDC disc into your optical drive. Note: The CD for the MT9234MU‐CDC utilizes the Autorun feature. You should exit the CD menu if it appears during the install process. Click the Next button. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 13 Downloaded from Elcodis.com electronic components distributor...
Page 14
Chapter 2 ‐ Installation After searching the CD and finding the necessary file, a pop‐up window for Windows Security will ask if you want to install the device software from Multi‐Tech Systems Incorporated. Click the Install button. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 15
Chapter 2 ‐ Installation Windows will now finalize the installation. When the software for this device has been successfully installed screen appears with Windows has finished installing the driver software for this device: MultiMobile MT9234MU‐CDC. Click Close. After installation has been completed and you have Internet access setup, you should test the operation of your new MT9234MU‐CDC by registering it. Key in the URL given below and follow the on‐line instructions: http://www.multitech.com/en_US/TOOLS/Forms/register/warranty.asp Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 15 Downloaded from Elcodis.com electronic components distributor...
Chapter 2 ‐ Installation Installing the Modem in Windows XP and Server 2003 or 2008 If you did not use the pre‐installer for Windows, this is the process for installing your modem. This installation assumes a Windows Server 2008, XP, or 2003 operating system. The procedure below was completed with Windows XP; the other operating systems listed will have a similar sequence and screens. Connect the USB cable between the MultiModem and the PC. Insert the MultiMobile MT9234MU‐CDC CD into your CD‐ROM drive. The CD uses the Autorun feature, and after a brief delay, the MultiMobile MT9234MU‐CDC Setup – Welcome screen appears. Close the Welcome screen. In some situations, the operating system will display a Found New Hardware Wizard screen and asks you: Can Windows connect to Windows Update to search for software? Select No, not this time. Then click Next. The Found New Hardware Wizard screen helps you install the software for MT9234MU‐CDC. Click Install from a list or specific location (Advanced), and then click Next. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 17
Chapter 2 ‐ Installation The next screen is the Please choose your search and installation options. Select only Search removable media (floppy, CD‐ROM…). Click Next. Please wait while the wizard searches for the MT9234MU‐CDC. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 17 Downloaded from Elcodis.com electronic components distributor...
Page 18
Chapter 2 ‐ Installation You may be prompted by the Windows Logo check. It is safe to continue (select to Continue Anyway) as the installation file has passed certification testing for Windows Vista (all other operating systems may display a certification warning). Please wait while the wizard installs the software. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Page 19
Chapter 2 ‐ Installation At the ‘Completing the Found New Hardware Wizard’ screen for the MultiMobile MT9234MU‐ CDC click Finish. Installation is now complete. After the installation has been completed and you have Internet access setup, you should test the operation of your new MT9234MU‐CDC by registering it. Key in the URL given below and follow the on‐line instructions: http://www.multitech.com/en_US/TOOLS/Forms/register/warranty.asp Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) 19 Downloaded from Elcodis.com electronic components distributor...
You must enter these commands in your communication program’s terminal window. If you do not have a terminal program available, please use the Global Wizard Utility as outlined above. To configure the modem for a specific country, execute the following AT commands: Type AT%T19,0,nn (where nn represents the country code). Press Enter. The modem will respond “OK.” Type AT&F&W (this saves changes). Press Enter. The modem will respond “OK.” Type ATI9 (this verifies that country code has been chosen). Press Enter. The modem will display the country code in decimal format followed by an “OK.” Check to be sure the code for your country is displayed. If not, repeat procedure to correct. Here is an example of country, command, and result codes. Example Country/Region AT Command Country Code (Hexadecimal) (Decimal) Euro/NAM* AT%T19,0,34 (default) 52 The complete list of country/region codes can be found on the Multi‐Tech Web site at: http://www.multitech.com/en_US/PRODUCTS/Categories/Device_Networking/global_modems/configuration.asp#chart Then click on global modems. The Global Modem Country Approvals page displays. On this page you can view approvals, configuration strings and responses by country and product. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Chapter 3 ‐ Operation Chapter 3 – Operation Front Panel The MT9234MU‐CDC has 4 LEDs on the front panel indicating status, configuration, and activity: Data. The Data LED flashes when the modem is transmitting/receiving data to/from another modem. [CD] Carrier Detect. The CD LED lights when the modem detects a valid carrier signal from another modem. It is on when the modem is communicating with the other modem and off when the link is broken. [OH] Off‐Hook. The OH LED lights when the modem is off‐hook, which occurs when the modem is dialing, online, or answering a call. The LED flashes when the modem pulse‐dials. [TR] Terminal Ready. The TR LED lights when Windows detects and initializes the modem. Connecting to the Internet Your Multi‐Tech modem is your gateway to the Internet and the World Wide Web. To access the Internet and Web via your modem, you must establish a dial‐up account with an Internet service provider (ISP). To locate an ISP near you, look in a local directory or computer publication. Your ISP should provide you with the following information: • User name (also called user ID) • Password • Access number (the number you call to connect to the server) • Host name and/or domain name • Domain Name Server (DNS) server address If, besides the Web, you use the Internet for e‐mail and newsgroups, your ISP should also provide you with the following information: • E‐mail or POP mail address • POP server address • Mail or SMTP address •...
Chapter 3 ‐ Operation Chapter 4 – Remote Configuration Remote configuration is a network management tool that allows you to configure modems anywhere in your network from one location. With password protected remote configuration, you can issue AT commands to a remote MT9234MU‐CDC modem for maintenance or troubleshooting as if you were on site. Basic Procedure The following steps are valid regardless of whether the connection is established by the local or the remote Multi‐Tech modem. 1. Establish a data connection with a remote MT9234MU‐CDC modem. 2. Send three remote configuration escape characters followed by AT and the setup password, and press ENTER. Example: %%%ATMTSMODEM. You have four tries to enter the correct password before being disconnected. If the password is correct, the remote modem responds with OK. 3. You can now send AT commands to configure the remote modem. 4. When you have finished configuring the remote modem, save the new configuration by typing AT&W0, and pressing Enter. 5. Type ATO and press Enter to exit remote configuration. You can then break the connection in the normal way. CAUTION: If you hang up while you are in remote configuration mode, it may lock up the remote modem. Setup Multi‐Tech modems are shipped with a default setup password (MTSMODEM). Because anyone who has an owner’s manual knows the default setup password, for security you should change the password and possibly also the remote configuration escape character. Changing the Setup Password 1. Open a data communications program such as HyperTerminal. To change the password, type AT#S=xxxxxxxx, where xxxxxxxx stands for the password, and press ENTER. The password can include any keyboard character, and must be one to eight characters long. The modem responds with OK. 3. The new password is saved automatically. You can now either enter more AT commands or exit the data communications program. The next time you remotely configure the modem you must use the new setup ...
Appendix A – Regulatory Compliance Appendix A – Regulatory Compliance FCC Part 15 Class B Statements This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to 47 CFR Part 15 regulations. The stated limits in this regulation are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Plug the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the 47 CFR rules. Operation of this device is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada This Class B digital apparatus meets all requirements of the Canadian Interference‐Causing Equipment Regulations. Cet appareil numerique de la classe B respecte toutes les exigences du Reglement sur le material brouilleur du Canada. FCC Part 68 Telecom 1. This equipment complies with part 68 of the Federal Communications Commission Rules. On the outside surface of this equipment is a label that contains, among other information, the FCC registration number. This information must be provided to the telephone company. 2. The suitable USOC jack (Universal Service Order Code connecting arrangement) for this equipment ...
Appendix A – Regulatory Compliance 5. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify you as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. 6. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make necessary modifications in order to maintain uninterrupted service. 7. If trouble is experienced with this equipment (the model of which is indicated below) please contact Multi‐Tech Systems, Inc. at the address shown below for details of how to have repairs made. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. 8. No repairs are to be made by you. Repairs are to be made only by Multi‐Tech Systems or its licensees. Unauthorized repairs void registration and warranty. 9. This equipment should not be used on party lines or coin lines. 10. If so required, this equipment is hearing‐aid compatible. 11. Manufacturing Information: Manufacturer: Multi‐Tech Systems, Inc. Trade Name MultiMobile USB Model Number: MT9234MU Registration Number: AU7MM04B9234MU Service Center in USA: Multi‐Tech Systems, Inc. 2205 Woodale Drive Mounds View, MN 55112 U.S.A. ...
Appendix A – Regulatory Compliance EMC, Safety, and R&TTE Directive Compliance The CE mark is affixed to this product to confirm compliance with the following European Community Directives: • Council Directive 2004/108/EC of 15 December 2004 on the approximation of the laws of Member States relating to electromagnetic compatibility; and • Council Directive 2006/95/EC of 12 December 2006 on the harmonization of the laws of Member States relating to electrical equipment designed for use within certain voltage limits; and • Council Directive 1999/5/EC of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity. International Modem Restrictions Some dialing and answering defaults and restrictions may vary for international modems. Changing settings may cause a modem to become non‐compliant with national telecom requirements in specific countries. Also note that some software packages may have features or lack restrictions that may cause the modem to become non‐compliant. New Zealand Telecom Warning Notice 1. The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with minimum conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom’s network services. This equipment is not capable under all operating conditions of correct operation at the higher speed which it is designated. 33.6 kbps and 56 kbps connections are likely to be restricted to lower bit rates when connected to some PSTN implementations. Telecom will accept no responsibility should difficulties arise in such circumstances. 2. Immediately disconnect this equipment should it become physically damaged, and arrange for its disposal or repair. 3. This modem shall not be used in any manner which could constitute a nuisance to other Telecom customers. 4. This device is equipped with pulse dialing, while the Telecom standard is DTMF tone dialing. There is no guarantee that Telecom lines will always continue to support pulse dialing. ...
Appendix A – Regulatory Compliance For repeat calls to the same number: • There shall be no more than 10 call attempts to the same number within any 30‐minute period for any single manual call initiation, and • The equipment shall go on‐hook for a period of not less than 30 seconds between the end of one attempt and the beginning of the next attempt. For automatic calls to different numbers: • The equipment shall be set to ensure that automatic calls to different numbers are spaced such that there is no less than 5 seconds between the end of one call attempt and the beginning of another. For automatically answered incoming calls: • The equipment shall be set to ensure that calls are answered between 3 and 30 seconds of receipt of ringing. 8. For correct operation, total of the RNs of all devices connected to a single line at any time should not exceed 5. South African Notice This modem must be used in conjunction with an approved surge protection device. Thailand Approval Translation in Thai “This telecom device and equipment is conform to technical standard no….” or “This telecom device and equipment is conform to requirement to NTC” “เครื ่ อ งโทรคมนาคมและอุ ป กรณ น ี ้ มี ค วามสอดคล อ งตามมาตรฐานทางเทคนิ ค เลขที ่ ..” or ...
Appendix A – Regulatory Compliance Restriction of the Use of Hazardous Substances (RoHS) Multi‐Tech Systems, Inc. Certificate of Compliance 2002/95/EC Multi‐Tech Systems, Inc. confirms that this product now complies with the chemical concentration limitations set forth in the directive 2002/95/EC of the European Parliament (Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment ‐ RoHS) These Multi‐Tech Systems, Inc. products do not contain the following banned chemicals: Lead, [Pb] < 1000 PPM Mercury, [Hg] < 1000 PPM Hexavalent Chromium, [Cr+6] < 1000 PPM Cadmium, [Cd] < 100 PPM Polybrominated Biphenyl, [PBB] < 1000 PPM Polybrominated Diphenyl Ether, [PBDE] < 1000 PPM Maximum Soldering temperature = 260C (wave only) Notes: Lead usage in some components is exempted by the following RoHS annex; therefore, higher lead concentration could be found. a. Lead in high melting temperature type solders (i.e., tin‐lead solder alloys containing more than 85% lead). b. Lead in electronic ceramic parts (e.g., piezoelectronic devices). REACH Statement Registration of Substances: After careful review of the legislation and specifically the definition of an “article” as defined in EC Regulation 1907/2006, Title II, Chapter 1, Article 7.1(a)(b), it is our current view Multi‐Tech Systems, Inc. products would be considered as “articles”. In light of the definition in § 7.1(b) which requires registration of an article only if it contains a regulated substance that “is intended to be released under normal or reasonable foreseeable conditions of use,” our analysis is that Multi‐Tech Systems, Inc. products constitute nonregisterable articles for their intended and anticipated use. Substances of Very High Concern (SVHC) Per the candidate list of Substances of Very high Concern (SVHC) published October 28, 2008 we have reviewed these substances and certify the Multi‐Tech Systems, Inc. products are compliant per the EU “REACH” requirements of less than 0.1% (w/w) for each substance. If new SVHC candidates are published by the European Chemicals Agency, and relevant substances have been confirmed, that exceeds greater than 0.1% (w/w), Multi‐Tech Systems, Inc. will provide updated compliance status. Multi‐Tech Systems, Inc. also declares it has been duly diligent in ensuring that the products supplied are compliant through a formalized process which includes collection and validation of materials ...
Appendix A – Regulatory Compliance Appendix B – Waste Electrical and Electronic Equipment July, 2005 The WEEE directive places an obligation on EU‐based manufacturers, distributors, retailers, and importers to take‐back electronics products at the end of their useful life. A sister Directive, ROHS (Restriction of Hazardous Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all Multi‐ Tech products imported into the EU as of August 13, 2005. EU‐based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. Instructions for Disposal of WEEE by Users in the European Union The symbol shown below is on the product or on its packaging, which indicates that this product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the seller from whom you purchased the product. Multi‐Tech Systems, Inc. MT9234MU‐CDC User Guide (S000470A) Downloaded from Elcodis.com electronic components distributor...
Appendix C – C‐ROHS HT/TS Appendix D – ASCII Conversion ASCII Conversion Chart CTRL CODE HEX DEC CODE HEX DEC CODE HEX DEC CODE HEX DEC " & < > NUL Null, or all zeros VT Vertical Tab SYN Sync. SOH ...
Appendix D – ASCII Conversion Index A R AT Commands .............. 5 REACH Statement ............. 27 Remote configuration ............ 22 C escape character ............ 22 Remote node operation ........... 21 Carrier detect LED ............. 2 1 S D Safety Warning Telecom ............ 4 Data LED ................ 2 1 Servicing your modem ............ 24 S‐registers S9 .............. 22 E T EMC, Safety, and R&TTE Directive Compliance .... 2 5 Terminal ready LED ............ 21 L W ...
