Multitech MultiConnect Cell 100 Series Quick Start

MultiConnect ® Cell 100 Series Cellular Modem Cat M1
Installing the Cellular Modem
1. Connect the antenna to the antenna connector (CELL).
Finger-tighten.
2. For serial models, connect to the device interface:
a. Connect the DE-9 connector (9-pin) of an RS-232
cable to the RS-232 connector on the cellular modem.
b. Connect the other end to the serial port on your
computer or other device.
c. Attach the power blades to the power supply.
d. Attach the power supply to the power connector on the
cellular modem. Finger-tighten.
e. Plug the power supply into your power source.
3. For USB models, connect to the device interface:
a. Connect the mini-USB connector end of the cable to
the device's USB connector.
b. Connect the USB cable's other end to your computer,
either directly or through a hub.
After power is applied:
■
The POWER LED lights after the device powers up.
■ When the LS LED begins to blink, the device is registered.
Mounting Device
1. Locate the groove on the bottom of the cellular modem.
2. Slide the mounting rod through the groove.
3. To secure the rod to the desired surface, place and tighten
two screws in the holes on either end of the mounting rod.
Refer to the user guide for an illustration of the mounting
rod, as well as the dimensions for placement of the screws.
