REbus Beacon
TOU Scheduler
running, overridden
Next Change:
To:
Schedule:
Figure 6-24. Overriding Scheduler
•
The countdown timer on the Beacon device page
will indicate the remaining time until the next mode
change.
After the next scheduled mode change, the scheduler will
resume normal operation.
Disabling the TOU Scheduler in Anticipation of a
Grid Outage
In the event of an impending storm and potential outage,
top off the battery by disabling the scheduler and switch-
ing the system mode to priority backup or clean backup
mode.
To disable the TOU Scheduler:
1. Navigate to the Beacon device page and disable
the scheduler. See
more information.
2. Navigate to the system home page and change the
system mode to a backup-only mode, such as Pri-
ority Backup or Clean Backup.
3. Once the emergency has passed, re-enable the
scheduler. See Disabling Beacon TOU
information.
NOTE: If Priority Backup mode is not listed with the other
system modes, the system installer may have removed
the mode to comply with utility rules. Some utilities do not
permit a battery to charge from the grid.
Access Installer Configuration Tool
(optional)
The Installer Configuration Tool allows configuration and
provisioning of Generac PWRcell systems from a smart-
phone or laptop. The interface allows installers to config-
ure basic settings, set inverter compliance, generate a
compliance report, and understand system performance.
The interface is only available on Generac PWRcell sys-
tems with a REbus Beacon installed. Close proximity to
the Beacon is required for use. It is not possible to
access this tool remotely. 45 minutes after being acti-
vated, the Beacon's WIFI signal will time out and may
need to be reactivated.
Installation and Owner's Manual for Generac PWRCell Inverter
1h:37m
Self Supply
SDGE
010119
Disabling Beacon TOU
for more
NOTE: All PWRcell Inverters come with a REbus Bea-
con pre-installed.

How to Access the Installer Configuration Tool

1. Navigate to the Beacon device page on the PWR-
cell Inverter control screen and press the center
button.
2. Select Installer Tool from the menu and click Con-
firm. This will activate the Beacon's Wi-Fi network.
3. Use a smartphone or laptop to connect to the Wi-Fi
network SSID titled: REbus_Beacon_xxxx where
xxxx is the last 4 digits of the Beacon's RCP num-
ber.
NOTE: The Beacon's RCP number can be found on the
front of the Beacon located inside the inverter, as well as
on the Beacon device page through the inverter's screen.
To find this number through the inverter's screen press
the center button on the Beacon device page. The RCP
number will be displayed at the bottom of the menu
screen.
4. Type in the password (labeled "CODE") for the
REbus Beacon's Wi-Fi network.
NOTE: The code for the REbus Beacon's Wi-Fi network
is located on the back of the Beacon inside of the
inverter. The Beacon is mounted on the upper left-hand
sidewall of the inverter housing. Unstick the Beacon to
view the code labeled on the back.
for
NOTE: Where utility requirements contain provisions for
security against adjusting compliance settings, consider
removing code label for the Beacon after successful
commissioning.
5. See
Figure
phone or laptop and enter 10.10.10.10 for the
browser URL. The installer tool will appear in the
browser.
Figure 6-25. Installer Configuration Tool
Commissioning
6-25. Open a web browser on a smart-
010981
37
