Figure 7-17. PV + Storage - Partial Home (1 of 2)
TargMinImprtP
Enalslanding
NumTranSwtchs
ExTransVolt
Cancel
Figure 7-18. PV + Storage - Partial Home (2 of 2)
PV + Battery w / a PWRcell ATS and SMMs for
Whole Home Backup
– System mode should be Self Supply, Clean
Backup, or Priority Backup.
– See Figure 7-19,
Inverter "Mod. Settings:"
o 'EnaIslanding' should be 'on.'
o 'NumTranSwtchs' should be '1.'
o'EnaLoadShed' should be '1' for SMMs
only and '2' for SMMs + PWRcell ATS
Controller for HVAC controls.
o All other settings should be at their default
values.
TargMinImprtP
EnaIslanding
NumTranSwtchs
ExTransVolt
Cancel
Figure 7-19. PV + Storage - Whole Home (1 of 3)
