What your Package Contains

1) COSEC ARGO Unit 6) Power Adapter 12VDC,2A
2) Flush Mounting Plate 7) Power Supply Cable (with DC Jack)
3) Four Screws M5/25 8) EM Lock Cable
4) Four Screw Grips
9) External Reader Cable
5) Overswing Diode
10) Flush Mounting Template

Preparation for Installation

Before Wall Mounting and Flush Mounting of COSEC ARGO follow below
instructions.
Remove the mounting screw from mounting screw hole of the bottom
•
of device as shown in Figure 3. The screw will be required to fix the
device after Wall Mounting or Flush Mounting.
Slide the back plate downwards to unlock the device from the
•
mounting hook and then remove it by pulling it outwards. This back
plate server as the Wall Mounting plate. For details see Installation
Instructions for Wall Mounting.
The Flush Mounting plate is available in the package. This plate will be
•
required for Flush Mounting of COSEC ARGO. For details see
Installation Instructions for Flush Mounting.
Wall Mounting: Select a location. It must be a flat surface such as wall,
close to the access point (door).
Flush Mounting: Select a wooden door or a location where the duct can be
made. The rectangular duct has to be made in the wooden door in which
Flush Mounting plate will be installed.
7
For Concealed wiring in Wall Mounting/Flush Mounting, first draw out
the sufficient length of the cables from the hole of the mounting plate.
For Non-concealed wiring in Wall Mounting; the knock -out area has to be
removed from outside by pressing on the bottom duct as shown
in Figure 3.
The connection of EM Lock must be done using the diode for Back
EMF protection.
