Know your COSEC ARGO

The COSEC ARGO is available in two series with three
different variants in each series as follows:
1) COSEC ARGO with variants FOE212, FOM212 and
FOI212.
2) COSEC ARGO with variants CAE200, CAM200 and
CAI200.
Front View
ARGO (FOE212/ FOM212/ ARGO (CAE200/ CAM200/
FOI212) CAI200)
Figure 1b
Figure 1a
Touch Screen
Display
Finger Sensor
Card Sensing
Area
3
Rear View (Common for both Series)
Figure 2
Bottom View (Common for both Series)
Touch Screen
Display
Figure 3
Card Sensing
Area
Back Plate or
Wall Mounting Plate
Flush
Mounting
Plate
Mounting Screw Hole
Knock Out Area
4
