Know your COSEC ARGO FACE200T
Please read this guide first for correct installation and retain
it for future reference. The information in this guide has been
authenticated at the time of publication. However, Matrix
Comsec reserves the right to make changes in product
design and specifications without prior notice.
3
7
7
9
15
21
23
28
32
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Matrix COSEC ARGO FACE200T
Summary of Contents for Matrix COSEC ARGO FACE200T
-
Page 1: Table Of Contents
Please read this guide first for correct installation and retain it for future reference. The information in this guide has been authenticated at the time of publication. However, Matrix Comsec reserves the right to make changes in product design and specifications without prior notice. - Page 2 Know your COSEC ARGO FACE200T Figure 3: Rear View Figure 1: Front View Touch Screen Display RGB Camera IR Camera IR LED Figure 2: Bottom View Mounting Screw Hole Back Plate or Wall Mounting Plate Flush Mounting Plate Knock Out Area...
- Page 3 Pre-Installation Safety Instruction Figure 6 1. Do not install the device in extremely hot temperature or under direct Sunlight or at extra bright places. This may affect the LCD and Camera sensor of device. You can do indoor installation as shown in Figure 4.
-
Page 4: Cosec Argo Face200T
The Flush Mounting plate is available in the package. This plate will be Built In Cameras • required for Flush Mounting of COSEC ARGO FACE200T. For details see Installation Instructions for Flush Mounting. For providing efficient Face Recognition, two Cameras are used in •... -
Page 5: Installation Instruction: Wall Mounting
Installation Instruction: Wall Mounting Step 2: Drill the screw holes along the traced markings. Fix Wall Mounting plate with the supplied screws. Tighten the screws with a screw driver. Step 1: Place the Wall Mounting plate and trace screw holes 1 and 2 on the wall where the device is to be installed. - Page 6 Step 3: Connect the cables of the COSEC ARGO FACE200T unit and • Keep the cables parallel to the side of the COSEC ARGO lead the cables through the duct of the Wall Mounting plate into the FACE200T body in such a way that it should not cover the electrical box recessed in the wall i.e.
- Page 7 Step 4: Align COSEC ARGO FACE200T on the mounting plate Step 5: Insert the mounting screw into the mounting screw hole and hook it into the mounting slot. Press the bottom side inwards at the bottom of the device. Tighten the screw to complete the to lock it in place.
-
Page 8: Installation Instruction: Flush Mounting
Installation Instruction: Flush Mounting Step 2: Place and fix the Flush Mounting plate with the supplied screws. Tighten the screws with a screw driver. Step 1: Place the Flush Mounting Template on the desired installation surface. Figure 9 Mark the area along the dotted line and trace the four screw •... - Page 9 Step 3: Connect the cables of the COSEC ARGO FACE200T unit Keep the cables parallel to the side of the COSEC ARGO • and lead the cables through the Flush Mounting plate into the FACE200T body in such a way that it should not cover the electrical box recessed in the wall.
- Page 10 Step 5: Insert the mounting screw into the mounting screw hole Step 4: Align COSEC ARGO FACE200T with the Flush Mounting at the bottom of the device. Tighten the screw to complete the plate and hook it into the mounting slot. Press the bottom side Flush Mounting.
-
Page 11: Connecting The Cables
Power Connect the Power cable to the 20 PIN connector affixed on • GND- Black the back side of the COSEC ARGO FACE200T Unit. +12VDC IN- Red Connect the Ethernet Cable to the LAN port. • Connect the micro USB port to the Printer or Broadband •... -
Page 12: Configuring The Settings From Argo Face200T
Configuring the Settings from ARGO FACE200T Setting the Device and Server Address from Menu Assigning IP/ Server Address to Device (For first time user only) Figure 22: Enter Password Figure 21: Tap Menu Figure 17: Set IP Address Figure 18: Set Server Address (Static/ Dynamic) (COSEC CENTRA) In case of COSEC VYOM... - Page 13 Figure 27: Tap Server Figure 23: Tap Admin Figure 24: Tap Settings Figure 28: Set the Server Configurations (COSEC CENTRA) In case of COSEC VYOM Figure 29: Select Server as VYOM Figure 26: Set the LAN Configurations Figure 30: Set the Server Configurations Figure 25: Tap LAN (COSEC VYOM)
-
Page 14: Configuring The Settings From Argo Face200T Web Page
Make sure the Monitor Service is running. Configuring the Settings from ARGO FACE200T Web Open the Web Browser in your computer. • Enter the IP Address of the COSEC ARGO FACE200T, • default: http://192.168.50.1 in the address bar of the browser and press the Enter key on your computer keyboard. - Page 15 Figure 36 Click Basic Profile and select the desired Server Connection – • COSEC CENTRA or COSEC VYOM, see Figure 35. Figure 35 For COSEC VYOM Click Server Settings. • Enter the Tenant ID, for example see Figure 37. • For COSEC CENTRA Click the Submit button, the Web Server URL (Address) and •...
-
Page 16: Technical Specification
Figure 37 Technical Specification Event Buffer 5,00,000 Input Power 12V DC @2A and PoE Credential Face, PIN, QR Code Support Built In PoE PoE (IEEE 802.3 af) Display 3.5 inch Capacitive IPS touch screen with Gorilla glass 3.0; Resolution: 480x320 pixels (HVGA) User Capacity 50,000 Communication... - Page 17 FCC Compliance Technical Specification This device complies with part15 of the FCC rules. Operation is subject to the following two conditions: Operating -10 °C to +50 °C Temperature 1. This device may not cause harmful interference. 2. This device must accept any interference received, including Dimensions 186mm x 74mm x 50mm (Wall Mount) interference that may cause undesired operation.
- Page 18 If you are unable to dispose-off the products or unable to locate e-waste recyclers, you may return the products to Matrix Return Material Authorization (RMA) department. Copyright All rights reserved. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Matrix Comsec.
- Page 19 MATRIX COMSEC PVT. LTD. Head Office 394-GIDC, Makarpura, Vadodara, Gujarat, 390010, India Ph: (+91)1800-258-7747 Email: Tech.Support@MatrixComSec.com Website: www.matrixcomsec.com...
