10 / 36
5.4

End clamp

Table 3: End clamps
Ordering code
SUP-M01-ENDHALTER
5.5

Wear parts

There are no wear parts in the extension modules.
6

Ambient conditions

Table 4: Ambient conditions
Area of application
Ambient temperature during operation
Ambient temperature during storage and transport -40 °C to +85 °C
Permitted air humidity
Mechanical strength
①
Overvoltage category
Contamination level
Degree of protection
Protection class
The vibration stress specifications assume the use of industrial-suited RJ45 plug connec-
①
tions. The "Industrial RJ45 plug" of the company Yamaichi is recommended (Y-ConPlug-41).
The cables are available as accessories (RKB0020). To avoid vibration, secure the cables at
a short distance (< 20 cm).
Bosch Rexroth AG
Part number Description
R911170685 2 pieces of snap-on end brackets for 35 mm NS
35/7.5 or NS 35/15 carrier plate; width: 9.5 mm
Only in interior spaces
Up to 2000 m:
-25 °C to +60 °C
2000 m to 3000 m:
-25 °C to +55 °C
5 % to 95 % acc. to DIN EN 61131-2
Condensation not allowed
Vibration stress
•
•
Shock stress: Shock resistance in all three axes
acc. to DIN EN 60068-2-27
11 ms semi-sinusoidal 30 g
2
2
IP20 acc. to DIN EN 60 529
III, DIN EN 61010-2-201
Oscillations, sinusoidal in all three axes acc. to
DIN EN 60068-2-6
5-9 Hz with an amplitude of 3.5 mm
9-150 Hz with 5 g peak acceleration
Broadband noise acc. to DIN EN 60068-2-64
5-20-150 Hz with 0.572 g, 5 h per axis
IndraControl XFE 01.1
R911345570, Edition 06
