C h a p t e r
1
System Board
1.1
Features
The DX6G Plus is a dual-processor system board built on an
®
extended ATX baseboard utilizing two Pentium
II processors running
®
at 400/100 and 450/100 MHz or two Pentium
III processors running
at 500/100 and 550/100 MHz. It is integrated with the Intel 440GX
system controller, which consists of the PCI/AGP controller and the
PCI/ISA IDE accelerator (PIIX4E).
®
®
The Pentium
II and Pentium
III processor implements a Dynamic
Execution micro-architecture - a unique combination of multiple
branch prediction, data flow analysis, and speculative execution. This
means that it can deliver higher performance than the previous
®
Pentium
processor while maintaining binary compatibility with all
previous Intel Architecture processors.
®
The PCI/AGP controller host bus interface supports both Pentium
II
®
and Pentium
III with 100 MHz bus frequency. It also provides a 72-
bit DIMM that supports synchronous DRAM (SDRAM) DIMMs. The
PCI/AGP controller introduces a new technology, which is the
Accelerated Graphics Port (AGP) interface.
Supporting up to
533MB/sec MHz data transfer rate, the AGP interface boosts graphics
performance.
The PIIX4E is a multifunctional PCI device controller implementing
system functions including PCI IDE, universal serial bus (USB)
host/hub, and enhanced power management. It also supports Ultra
DMA/33 synchronous DMA-compatible devices.
System Board
1-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX6G Plus and is the answer not in the manual?

Questions and answers

Related Manuals for AOpen DX6G Plus

Summary of Contents for AOpen DX6G Plus

  • Page 1 C h a p t e r System Board Features The DX6G Plus is a dual-processor system board built on an ® extended ATX baseboard utilizing two Pentium II processors running ® at 400/100 and 450/100 MHz or two Pentium III processors running at 500/100 and 550/100 MHz.
  • Page 2 The four DIMM sockets on board allow memory upgrade to a maximum of 2048 MB and supports 72-bit DIMM using synchronous DRAM (SDRAM) DIMMs. Two 16-bit Ultra-2 SCSI (Small Computer System Interface) and an 8-bit fast narrow SCSI comes with the system board to connect SCSI devices.
  • Page 3 Major Components The system board has the following major components: • ® Supports dual Pentium II processors running at 400 or 450 ® MHz, Pentium III processors running at 500 or 550 MHz, and future generations Pentium CPUs. • Four DIMM sockets that accept 16-, 32-, 64- 128-, 256 and 512MB DIMMs with a maximum of 2048 MB system memory •...
  • Page 4 Layout Mouse port System BIOS Keyboard port RDM connectors Serial port 2 Channel 1 Ultra-wide/Ultra-2 SCSI Parallel port connector (68 pin) Serial port 1 Channel 2 Ultra-wide/Ultra-2 SCSI USB connector connector (68 pin) RJ-45 Channel 2 fast/narrow SCSI LAN controller connector (50 pin) AGP slot FDD connector...
  • Page 5 Jumpers and Connectors 1.4.1 Jumper and Connector Locations Jumpers are prefixed P”. Connectors are prefixed N”. The blackened pin of a jumper or connector represents pin 1. System Board...
  • Page 6 1.4.2 Jumper Settings The table below lists the system board jumpers with their corresponding settings and functions. Jumper Setting Function BIOS Logo Logo Password Security Check password 2-3* Bypass password Boot Block Mode Disabled 2-3* Enabled Sound Output 1-2* Buzzer Speakers SCSI Channel 1Terminator 1-2*...
  • Page 7 1.4.3 Connector Functions The table below lists the different connectors on the system board and their respective functions. Connector Function Cabinet Fan Connector 337W Power Supply Connector (3.3V and 5V) Mouse and Keyboard Ports ATX Power Connector Power Supply Connector Modem Card Ring-in Connector CN10 Parallel (above), Serial 1(left), and Serial 2 (right)
  • Page 8 Connector Function CN33 SCSI Channel 2 Narrow Connector CN34 RDM LED Connector CN35 External Speaker Connector CN36/CN37 External LED Connector CN38 Power Switch Connector CN39/CN47 CN40 Wake-on-LAN (WOL) Connector CN42 3-pin Standby Power Connector CN43 Hard Disk LED Connector CN44 Reset Button Connector CN45 Feature Connector (Intel SMM Card)
  • Page 9 ESD Precautions Always observe following electrostatic discharge (ESD) precautions before installing a system component: Do not remove a component from its antistatic packaging until you are ready to install it. Wear a wrist grounding strap before handling electronic components. Wrist grounding straps are available at most electronic component stores.
  • Page 10 Installing the Pentium II and Pentium III processors The following section will briefly explain and illustrate how to install the Pentium II and Pentium III processors. You have to attached the fan sink before installing the processor into the system board.
  • Page 11 Follow these steps when installing the fan sink and fan into the processor module: 1. Remove the thermal tape protector at the back of the fan sink. Insert the wide clip ends into the wide holes on the processor and the narrow clip ends into the narrow holes.
  • Page 12 3a. Use a screwdriver to press and lock in the wide end of a clip first. Then without lifting the screwdriver, point it downward to press and lock the narrow end of the clip. 3b. Using your fingers, push down the metal bracket until it clicks into the CPU cartridge and then push the metal bracket handle to lock the metal bracket into place.
  • Page 13 1.6.2 Installing a Pentium II or Pentium III Processor Follow these steps to install the processor to the socket on the CPU board. 1a. Place the retention mechanism over the processor socket on the CPU board. Secure it with the screws that came with the package.
  • Page 14 With the processor module golden fingers pointing downward, align the processor to the posts of the retention mechanism then lower it down. The golden fingers of the processor module are slotted such that it only fits in one direction. Make sure that the module groove matches the one on the processor socket.
  • Page 15 1.6.3 Removing a Pentium II or Pentium III Processor Follow these steps to remove the processor module from the CPU slot. Unlock the latches that secure the processor module. Firmly hold the processor module and pull it out of the socket. System Board 1-15...
  • Page 16 DIMMs for a maximum of 2048-MB system memory. The SDRAM DIMMs should work under 3.3 volts only; 5 volt memory devices are not supported. DX6G Plus supports both 100MHz standard and registered SDRAM. However, please do not use them at the same time.
  • Page 17 DIMM1 DIMM2 DIMM3 DIMM4 Total Memory 128 MB 128 MB 128 MB 384 MB 128 MB 128 MB 128 MB 128 MB 512 MB 256 MB 256 MB 256 MB 256 MB 512 MB 256 MB 256 MB 256 MB 768 MB 256 MB 256 MB...
  • Page 18 1.7.3 Removing a DIMM To remove a DIMM, press the holding clips on both sides of the socket outward to release the DIMM. Place your forefingers on the top of the DIMM before you press the holding clips to gently disengage the DIMM from the socket. 1.7.4 Reconfiguring the System Reconfigure the system after installing or removing DIMMs.
  • Page 19 Installing Expansion Cards 1.8.1 Installing PCI Cards To install PCI cards: Locate the PCI slots on the system board. Remove the bracket on the housing opposite an empty PCI slot. Insert a PCI card into the slot. Make sure that the card is properly seated.
  • Page 20 Follow these steps when installing ISA cards: Remove all PnP cards installed in the system, if any. Install non-PnP ISA cards. Turn on the system. Use the operating system or ICU to manually assign the appropriate IRQs to the cards. This ensures that BIOS will not use the resources assigned to the non-PnP ISA cards.
  • Page 21 1.8.3 Installing AGP Card When installing an AGP card, make sure that the IRQ required by the card is not already assigned to a PCI or ISA device to avoid resource conflicts. Follow these steps when installing an AGP card: 1.
  • Page 22 LDCM Intel® LANDesk® Client Manager Version 3.3 is an application that simplifies local and network management of mobile and desktop client systems. It monitors PC health to provide local and remote alerts. It gives local and remote views of hardware and software component, even via dial-up.
  • Page 23 1.10 Error Messages Do not continue using the computer if you receive an error message of any type. Note the message and take corrective action. This section explains the different types of error messages and corresponding corrective measures. There are two general types of error messages: •...
  • Page 24 Message Action Diskette Drive Controller Error Check and connect the control or Not Installed cable to the diskette controller. Diskette Drive Error Check the CMOS settings in Setup and the diskette drive cable connections. Diskette Drive A Type Run Setup and select the proper Mismatch drive type.
  • Page 25 Message Action Memory Size Mismatch Check the memory size based on the system specifications. Check CPU Clock Mismatch the internal cable connections. If you are sure that connections and values are correct, ignore the message. If the message reappears, ask for technical assistance.
  • Page 26 1.10.3 Correcting Error Conditions As a general rule, if an error message says "Press F1 to continue," it is caused by a configuration problem, which can be easily corrected. An equipment malfunction is more likely to cause a fatal error, i.e., an error that causes complete system failure.
  • Page 27 C h a p t e r Setup Utility Most systems are already configured by the manufacturer or the dealer. There is no need to run Setup when starting the computer unless you get a Run Setup message. The Setup program loads configuration values into the battery-backed nonvolatile memory called CMOS RAM.
  • Page 28 Entering Setup To enter Setup, simultaneously press the key You must press while the system is booting. This key combination does not work during any other time. The Setup Utility Main Menu appears: Setup Utility • System Information • Product Information •...
  • Page 29 If you are an advanced user, you may want to check the detailed configuration of your system. Detailed system configurations are contained in the Advanced Level. To view the Advanced Level, press The asterisk (*) mark indicates that the parameter appears only when you are in the Advanced Level.

  • Page 30: Table Of Contents

    System Information Processor ......Pentium® II Processor Speed..... 400 MHz Internal Cache...... 32 KB, Enabled External Cache...... 512 KB, Enabled Diskette Drive A....1.44 MB, 3.5-inch Diskette Drive B....None IDE Primary Channel Master ..Hard Disk, xxx MB IDE Primary Channel Slave ... None IDE Secondary Channel Master..

  • Page 31: Processor

    2.2.1 Processor The Processor parameter specifies the type of processor currently installed in your system. The system supports Intel Pentium® II and Pentium® III processors. 2.2.2 Processor Speed The Processor Speed parameter specifies the speed of the processor currently installed in your system. 2.2.3 Internal Cache This parameter specifies the first-level or the internal memory (i.e., the...

  • Page 32: Ide Primary Channel Master

    2.2.7 IDE Primary Channel Master This parameter specifies the current configuration of the IDE device connected to the master port of the primary IDE channel. 2.2.8 IDE Primary Channel Slave This parameter specifies the current configuration of the IDE device connected to the slave port of the primary IDE channel.

  • Page 33: Serial Port 1

    2.2.12 Serial Port 1 This parameter shows the serial port 1 address and IRQ setting. 2.2.13 Serial Port 2 This parameter shows the serial port 2 address and IRQ setting. 2.2.14 Parallel Port This parameter shows the parallel port address and IRQ setting. 2.2.15 PS/2 Mouse The BIOS utility automatically detects if there is a pointing device...
  • Page 34 The following shows how the Product Information screen appears: Product Information Product Name ......DX6G Plus System S/N ......xxxxxxxxx Main Board ID ......DX6G PLUS Main Board S/N ......N/A System BIOS Version ....v3.1 R0.01 SMBIOS Version ......2.1 System BIOS ID ......
  • Page 35 This parameter specifies the version of the BIOS utility. 2.3.6 SMBIOS Version This parameter specifies the version of the SMBIOS version. 2.3.7 System BIOS ID This parameter specifies AOpen BIOS ID. 2.3.8 BIOS Release Date This parameter specifies the BIOS release date. Setup Utility...
  • Page 36 Disk Drives Select Disk Drives to input configuration values for disk drives. The following screen shows the Disk Drives menu: Disk Drives Diskette Drive A....... [xx-MB, xx-inch] Diskette Drive B....... [ None LS-120 Drive as......[ Normal ] • IDE Primary Channel Master •...
  • Page 37 Follow the same procedure to configure floppy drive . Choose None if you do not have a second floppy drive. 2.4.2 LS-120 Drive As This parameter allows you not only to enable the LS-120 device installed in your system, but also to specify the function of the device. The setting affects how BIOS will detect the device.
  • Page 38 IDE Primary Channel Master This parameter lets you configure the hard disk drive connected to the master port of IDE channel 1. IDE Primary Channel Slave This parameter lets you configure the hard disk drive connected to the slave port of IDE channel 1. IDE Secondary Channel Master This parameter lets you configure the hard disk drive connected to the master port of IDE channel 2.

  • Page 39: Type

    The above parameters marked with ‘*’ will only appear if you access the advanced level option in the Main Menu. Please refer to section 2.1 for more information. TYPE This parameter lets you specify the type of hard disk installed in your system.

  • Page 40: Hard Disk Size > 504Mb

    Enhanced IDE Features HARD DISK SIZE > 504 MB When set to Auto , the BIOS utility automatically detects if the installed hard disk supports the function. If supported, it allows you to use a hard disk with a capacity of more than 504 B. This is made possible through the Logical Block Address (LBA) mode translation.

  • Page 41: Dma Transfer Mode

    DMA TRANSFER MODE The Ultra DMA and Multi-DMA modes enhance hard disk performance by increasing the transfer rate. However, besides enabling these features in the BIOS Setup, both the Ultra DMA and Multi-DMA modes require the DMA driver to be loaded. By setting this parameter to Auto , BIOS automatically sets the appropriate DMA...
  • Page 42 Onboard Peripherals The Onboard Peripheral Configuration allows you to configure the onboard communication ports and the onboard devices. Selecting this option displays the following screen: Onboard Peripherals Serial Port 1....... [Enabled ] Base Address..... [3F8h] IRQ......[4] Serial Port 2....... [Enabled ] Base Address.....

  • Page 43: Base Address

    This function lets you assign an interrupt for serial ports 1 and 2. The options for serial ports 1 are IRQ . The options for serial port 2 are IRQ The Base Address and IRQ parameters for each port are configurable only if the port is enabled.

  • Page 44: Operation Mode

    Operation Mode This item allows you to set the operation mode of the parallel port. The table below lists the different operation modes. Setting Function Standard Parallel Port Allows normal speed one-way (Standard) operation Standard and Bidirectional Allows normal speed operation in a (Bidirectional) two-way mode Enhanced Parallel Port...
  • Page 45 Onboard Device Settings Floppy Disk Controller....[Enabled ] IDE Controller...... [Both PS/2 Mouse Controller....[Enabled ] USB Host Controller....[Enabled ] USB Legacy Mode....[Disabled] Onboard SCSI......[Enabled ] Boot from SCSI Device..... [Enabled ] SMBus Interrupt(IRQ9)....[Disabled] Onboard Ethernet Chip....[Enabled ] Alert on LAN......
  • Page 46 USB LEGACY MODE This function, when enabled, lets you use a USB keyboard in DOS. Set this to to deactivate the USB keyboard function in DOS. Disabled Onboard SCSI Device This parameter lets you enable or disable the SCSI controller on board.
  • Page 47 Power Management The Power Management menu allows you to configure the system power-management feature. The following screen shows the Power Management parameters and their default settings: Power Management Power Management Mode....[Enabled] IDE Hard Disk Standby Timer..[Off] System Sleep Timer....[Off] Sleep Mode......
  • Page 48 System Sleep Timer This parameter sets the system to the lowest power-saving mode after a specified period of inactivity. Any keyboard or mouse action or any activity detected from the IRQ channels resumes system operation. SLEEP MODE This parameter lets you specify the power-saving mode that the system will enter after a specified period of inactivity.
  • Page 49 2.6.4 Boot Options This option allows you to specify your preferred setting for bootup. The following screen appears if you select Boot Options from the Basic Configuration menu: Boot Options Boot Sequence [Floppy Disk] [Hard Disk [IDE CD-ROM ] [LANDesk® Service Agent] First Hard Disk Drive....

  • Page 50: Nd [Hard Disk ]

    • The system then checks this drive if it can not boot from the specified drive. • If the searches fail then it boots from this drive. • If the searches fail then it boots from , and 3 this drive. BIOS will display an error message if the drive(s) specified is not bootable.

  • Page 51: Silent Boot

    2.6.8 Silent Boot This parameter enables or disables the Silent Boot function. When set to , BIOS is in graphical mode and displays only an Enabled identification logo during POST and while booting. After booting the screen displays the operating system prompt (such as DOS) or logo (such as Windows 95).

  • Page 52: Configuration Table

    2.6.12 Configuration Table This parameter allows you to enable or disable the appearance of the configuration table after POST but before booting. The configuration table gives a summary of the hardware devices and settings that BIOS detected during POST. 2.6.13 Boot from LANDesk Service Agent When set to Enabled...
  • Page 53 Date and Time The real-time clock keeps the system date and time. After setting the date and time, you do not need to enter them every time you turn on the system. As long as the internal battery remains good (approximately seven years) and connected, the clock continues to keep the date and time accurately even when the power is off.
  • Page 54 2.7.2 Time Highlight the items on the Time parameter and press to set the time following the hour-minute-second format. Valid values for hour, minute, and second are: • Hour • Minute • Second 2-28 User’s Guide...
  • Page 55 System Security The Setup program has a number of security features to prevent unauthorized access to the system and its data. The following screen appears if you select System Security from the Main menu: System Security Setup Password ....[None] Power-on Password ....
  • Page 56 Enable the Setup Password parameter in the System Security menu by pressing the arrow key. The Setup Password window appears: Setup Password Enter your new Setup Password twice. Setup Password may be up to 7 characters long. Enter Password....[xxxxxxx] Enter Password again....
  • Page 57 2. Open the computer housing and set JP4 to 1-2 (Check password) to check the password function. See section 1.4 for the location of JP4. 3. Close your computer housing and reboot your system. The next time you want to enter the BIOS utility, you must key in your Setup password.
  • Page 58 To bypass Setup Password: If you forget your setup password, you can bypass the password security feature by hardware. Follow these steps to bypass the password: Turn off and unplug the computer. Open the computer housing and set JP4 to 2-3 (Bypass password) to bypass the password function.
  • Page 59 Power-on Password Enter your new Power-on Password twice. Power-on Password may be up to 7 characters long. Enter Password ....[ Enter Password again .... [ Set or Change Password Operation Mode This function lets you enable or disable the password prompt display. When set to , the password prompt appears before system Normal...
  • Page 60 Hard Disk Drive Setting Description Normal Hard disk drive functions normally Write Protect All Sectors Disables the write function on all sectors Write Protect Boot Sector Disables the write function only on the boot sector 2-34 User’s Guide...
  • Page 61 System Event Log The system event log enables you to record and monitor events that occurs in your system like system temperature, fan stops, and others. This feature allows you to specify the appropriate settings for your system event handling. Selecting the option displays the following screen: System Event Log Page 1/2...

  • Page 62: Total Event Log Number

    TOTAL EVENT LOG NUMBER The number of events currently located in the event log area. REMAIN OF EVENT LOG AREA The percentage of space that is still available for logging system events. EVENT LOGGING This parameter allows you to enable or disable the event logging function of your system.

  • Page 63: Event Control

    Events Control This parameter monitors the following events and logs them into the event log file if there is a change in status. TEMPERATURE/VOLTAGE/FAN Enable or disable the monitoring of the system temperature, volume, and CPU fan. The default is Enabled ECC or Error-Correcting Code tests the accuracy of data as it passes in and out of memory.

  • Page 64: Move Highlight Bar, → ← = Change Setting, F1 = Help

    System Event Log Page 2/2 Critical Event Process Stop POST After CPU or Memory Reduction ..[Disabled] Halt System If No CPU or Memory Available ...[Enabled] Threshold Setting CPU Warning Temperature .....[ xx] °C CPU Fatal Temperature .......[ xx] °C System Temperature ......[ xx] °C System Voltage ......[ xx] % ↑↓...
  • Page 65 Threshold Setting CPU WARNING TEMPERATURE You can set a threshold for the CPU temperature level here and every time the CPU temperature exceeds this level a warning will be logged into the event log file. A typical warning degree threshold setting is 67°C.
  • Page 66 2.10 Advanced Options The Advanced Options configuration menu allows you to configure the system memory, PCI device settings, and CPU frequency. Do not change any settings in the Advanced Options if you are not a qualified technician to avoid damaging the system. The following screen shows the Advanced Options parameters: Advanced Options *•...
  • Page 67 2.10.2 PnP/PCI Options The PnP/PCI Options allows you to specify the settings for your PCI devices. Selecting this option displays the following screen: PnP/PCI Options PCI IRQ Setting ... [ Auto INTA INTB INTC INTD PCI Slot 1 ....[--] [--] [--] [--]...
  • Page 68 ONBOARD LAN When you set the PCI IRQ Setting parameter to , this parameter Auto specifies the auto-assigned interrupt for the onboard LAN. If you set the PCI IRQ Setting parameter to Manual , you need to specify the interrupt that you want to assign for the onboard LAN installed in your system.
  • Page 69 PCI Device Settings PCI Device Settings PCI Device Latency Timer ..[E0]H Clocks PCI IRQ Sharing....[Yes] VGA Palette Snoop ... [Disabled] Graphics Aperture Size..[64] MB Plug and Play OS..... [No ] Reset Resource Assignments... [No ] PCI DEVICE LATENCY TIMER This parameter allows you to set the length of time for a PCI device to use the PCI bus.
  • Page 70 VGA PALETTE SNOOP This parameter permits you to use the palette snooping feature if you installed more than one VGA card in the system. The VGA palette snoop function allows the control palette register (CPR) to manage and update the VGA RAMDAC (Digital Analog Converter, a color data storage) of each VGA card installed in the system.
  • Page 71 RESET RESOURCE ASSIGNMENTS Set this parameter to to avoid IRQ conflict when installing non-PnP or PnP ISA cards. This clears all resource assignments and allows BIOS to reassign resources to all installed PnP devices the next time the system boots. After clearing the resource data, the parameter resets to 2.10.3 Memory/Cache Options...
  • Page 72 CACHE SCHEME This parameter shows the cache scheme status only as Write-back mode. updates the cache but not the memory when Write-back there is a write instruction. It updates the memory only when there is an inconsistency between the cache and the memory. Memory at 15MB-16MB Reserved for To prevent memory address conflicts between the system and expansion boards, reserve this memory range for the use of either the...
  • Page 73 In cases when this parameter is enabled before installing Windows NT in a single-processor system, you may upgrade to a multiprocessor system without reinstalling Windows NT. Setup Utility 2-47...
  • Page 74 2.10.4 CPU Frequency This parameter displays your CPU speed and bus frequency. Selecting this option displays the following screen: CPU Frequency Bus Frequency....100 MHz CPU Multiple....[4] Processor Speed....xxx MHz Bus Frequency The bus frequency refers to the speed by which data is transferred between internal computer components and the CPU or the main memory of the CPU.
  • Page 75 Processor Speed The processor speed is the speed at which a microprocessor executes instructions. Clock speeds are expressed in megahertz (MHz), with 1 MHz being equal to 1 million cycles per second. The faster the clock, the more instructions the CPU can execute per second.
  • Page 76 2.11 Load Default Settings Use this option to load the default settings for the optimized system configuration. When you load the default settings, some of the parameters are grayed-out with their fixed settings. These grayed parameters are not user-configurable. The following dialog box appears when you select Load Default Settings from the main menu: Load Default Settings Do you want to load default settings?
  • Page 77 Select to ignore the message and return to the BIOS utility. 2.13 Exit Setup Examine the system configuration values. When you are satisfied that all the values are correct, write them down. Store the recorded values in a safe place. In the future, if the battery loses power or the CMOS chip is damaged, you will know what values to enter when you rerun Setup.
