Page 1 DOC. NO. : DX37PU-OL-E0112B Open...
Page 2 No part of this publication may be reproduced., stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopy, recording, or otherwise, without the prior written permission of Aopen Incorporated. All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective companies.
Page 3 Read these instructions carefully. Save these instructions for future reference. Follow all warnings and instructions marked on the product. Do not use this product near water. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. Slots and openings in the cabinet and the back or bottom are provided for ventilation;...
Page 4 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power cord or plug is damaged or frayed If liquid has been spilled into the product If the product has been exposed to rain or water If the product does not operate normally when the operating instructions are followed.
Page 5 DANGER INVISIBLE RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM. CLASS 1 LASER PRODUCT APPAREIL A LASER DE CLASSE 1 LASER KLASSE 1 LOUKAN 1 LASERLAITE PRODUIT LASER CATEGORIE 1 Open...
Page 6 CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 7 Notice 2 Shielded interface cables, if any, must be used in order to comply with the emission limits. Purpose This user’s guide aims to give you the information you need to operate the system properly and tells you how to install internal components.
Page 8: C Onventions
The following conventions are used in this manual: Text entered by user Represents text input by the user. , etc…. Represent the actual keys that you have to press on the keyboard. NOTE Gives bits and pieces of additional information related to the current topic. CAUTION Gives precautionary measures to avoid possible hardware or software problems.
Page 9: Table Of Contents
’ ’ Fortress 7700/7900 …………………………………………………………………………………………………………………………………..1 ....................................3 MPORTANT AFETY NSTRUCTIONS CD-ROM S ......................................5 AFETY ARNING ....................................6 AUTION ON ITHIUM ATTERIES FCC C ............................6 LASS ADIO REQUENCY NTERFERENCE TATEMENT ........................................7 BOUT THIS ANUAL ..........................................8 ONVENTIONS ’ ......................................9 S IN THIS MANUAL CHAPTER 1 HOUSING INSTRUCTION (SV320) ..............................20 1.1 I ........................................20 NTRODUCTION...
Page 10 1.5.1 3.5-inch Device Drive ....................................26 1.5.2 5.25-inch Device Drives....................................28 1.6 I ....................................30 NSTALLING AGES 1.6.1 Installing a HSC5 Hot-Swap Cage.................................30 1.6.2 Installing and Removing a HSC5 Hard Disk Drive Tray ..........................33 1.6.3 HSC5 LVD SCSI Backpanel Board ................................34 1.6.4 HSC5 Jumpers and Connectors..................................35 1.7 I ..................38 NSTALLING AND...
Page 11 Ultra DMA 33/66/100 Bus Mater IDE ..................................47 Intel 82550 LAN controller .....................................47 Power Management/Plug and Play..................................48 Hardware Monitoring Management..................................48 Super Multi-I/O........................................48 2.3 M ......................................49 OTHERBOARD 2.4 B ........................................50 LOCK IAGRAM 2.5 C ....................................51 ONNECTORS AND UMPERS 2.6 H ...........................................53 ARDWARE 2.6.2 CPU Installation ......................................55 2.6.3 CPU &...
Page 12 2.6.12 WOL (Wake on LAN)....................................69 2.6.13 Support 4 USB Connectors...................................71 2.6.14 SCSI LED Connector (For SCSI/RAID Card, DX37 Plus-U Only) ......................72 2.6.15 CD/AUX Connector .....................................73 2.6.16 PC99 Color Coded Back Panel..................................74 2.6.17 Support 10/100 Mbps LAN onboard................................75 2.6.18 Low ESR Capacitor......................................76 CHAPTER 3 BIOS SETUP UTILITY ..................................
Page 13 3.2.10 IDE Secondary Channel Master...................................82 3.2.11 IDE Secondary Channel Slave..................................82 3.2.12 Total Memory .......................................82 3.2.13 Serial Port 1.........................................83 3.2.14 Serial Port 2.........................................83 3.2.15 Parallel Port ........................................83 3.2.16 PS/2 Mouse ........................................83 3.3 P ......................................84 RODUCT NFORMATION 3.3.1 Product Name ........................................84 3.3.2 System S/N........................................85 3.3.3 Main Board ID .......................................85 3.3.4 Main Board S/N......................................85 3.3.5 System BIOS Version ......................................85...
Page 14 3.5.3 Onboard Device Settings....................................94 3.6 P ......................................98 OWER ANAGEMENT 3.6.1 Power Management Mode....................................99 3.6.2 Power Switch < 4 sec....................................100 3.6.3 System Wake-up Event....................................101 3.7 B ........................................103 PTIONS 3.7.1 Boot Sequence......................................104 3.7.2 Fast Boot........................................104 3.7.3 Silent Boot........................................105 3.7.4 Num Lock After Boot....................................
Page 15 3.9.4 Processor Serial Number ..................................... 112 3.10 S ......................................113 YSTEM VENT 3.10.1 System Event Logging ....................................114 3.10.2 Events Control......................................115 3.10.3 Event Process ......................................116 3.11 L ....................................117 EFAULT ETTINGS 3.12 A ....................................118 BORT ETTINGS HANGE CHAPTER 4 SCSISELECT™...
Page 16 4.3.6 Boot LUN Number Options ..................................132 4.3.7 Boot LUN Number ....................................... 133 4.4 A ................................137 DVANCED ONFIGURATION PTIONS 4.4.1 Host Adapter BIOS....................................... 138 4.4.2 Display <Ctrl-A> Message During BIOS Initialization..........................138 4.4.3 Extended BIOS Translation for DOS Drives > 1 GByte ..........................138 4.4.4 Support Removable Disks Under BIOS as Fixed Disks ..........................
Page 17 GLOSSARY ..........................................146 AC97 ............................................146 ACPI (A & P ) ............................. 146 DVANCED ONFIGURATION OWER NTERFACE AGP (A )..................................146 CCELERATED RAPHIC AMR (A ) ....................................147 UDIO ODEM ISER CD ......................................147 ONUS APM ............................................147 ATA/66............................................147 ATA/100............................................ 147 BIOS (B ) ..................................
Page 18 ROM..........................................150 LASH FSB (F ....................................151 RONT LOCK ............................................. 151 P1394............................................151 ..........................................151 ARITY PBSRAM (P SRAM) ..................................151 IPELINED URST PC100 DIMM ........................................... 152 PC133 DIMM ........................................... 152 PDF F ..........................................152 ORMAT P (P ) ......................................152 LUG AND POST (P ) ....................................
Page 19 VCM (V ) ..................................155 IRTUAL HANNEL EMORY ............................................ 155 FILE TROUBLESHOOTING ....................................156 TECHNICAL SUPPORT ......................................160 UMBER AND ERIAL UMBER ..............................161 PRODUCT REGISTRATION ....................................162 HOW TO CONTACT US ......................................163 Open...
Page 20: I Ntroduction
This installation guide describes the features of the SV320 housing and tells you how to install the basic system components such as disk drives, a motherboard, or expansion boards. If you receive a complete system, the basic components are already installed. The SV320 housing is designed both as standalone and rackmount system housing.
Page 21: Front Panel
1.3.1 Front Panel Key lock Panel Door Open...
Page 22: Rear Panel
1.3.2 Rear Panel COM port Outlets Hot-Swap Redundant Power Supply Housing Fan Expansion Slots SCSI Expansion Slots (Optional) Open...
Page 23: Internal Structure
1.3.3 Internal Structure Hot-swap Redundant Power Supply Housing Fan Expansion Card 5.25-inch Drive Bays Slots 3.5-inch Drive Bay Back-plane Board Power Switch Power LED Hot-Swap Cage Hard Disk Drive LED (SCSI) System Status LED (reserved) Removable Hard Disk Drive Trays Open...
Page 24: Front Panel
1.4.1 Front Panel Key lock To open the front panel, use the key to unlock and then pull the panel as shown in the illustration above. Open...
Page 25: Left Panel
1.4.2 Left Panel To remove the left panel: Use a screwdriver to remove the two front screws. Keep them in a safe place for later use. Pull the panel handle out and use it to remove the left panel from the housing. Left panel Screw Left Panel Handle...
Page 26: O Pening The H Ousing P Anels
Turn off the power switch and unplug the power cord before installing or removing diskette drives. 1.5.1 3.5-inch Device Drive To install 3.5-inch device drives: Open the front panel of the housing. See section 1.4.1 for more information on opening the housing panel. Detached the 3.5-inch drive frame (2 pieces) from the housing by removing two screws.
Page 27 Insert the drive into the drive bay and secure it with two screws. Connect the diskette drive cables and close the housing panels. Open...
Page 28: Inch Device Drives
1.5.2 5.25-inch Device Drives You may install a CD-ROM, digital-audio tape (DAT), hard disk, diskette drive or any other 5.25-inch device into the drive bay. To install 5.25-inch devices: Open the front panel. See section 1.4.1 for more information on opening the housing panel. Detached the 5.25-inch drive frame (2 pieces) from the housing by removing two screws.
Page 29 Insert the drive into the drive bay and secure it with two screws. Connect the signal and power cables to the drive and close the housing panels. Open...
Page 30: Installing A Hsc5 Hot-Swap Cage
The SV320 system housing comes with one HSC5 hot-swap cage. The HSC5 hot-swap cage box includes the following components: • One hot-swap cage (with back plane board attached) • Five hard disk drive tray • One SCSI terminator 1.6.1 Installing a HSC5 Hot-Swap Cage To install the hot-swap cage into the housing: Open the front panel and remove the left panel of the housing.
Page 31 We suggest you use the lower three 5.25” bays. Locate the LVD SCSI cable and remove the terminator located at the end of the LVD SCSI cable. Open...
Page 32 Attach the power cable and the LVD SCSI cable to the backpanel board. The LVD SCSI cable can be connected to either onboard SCSI channel A or B (channel B recommended), or RAID card to form a RAID configuration. Power connector SCSI Terminator Connect to the system power supply...
Page 33: Installing And Removing A Hsc5 Hard Disk Drive Tray
1.6.2 Installing and Removing a HSC5 Hard Disk Drive Tray To remove and install a HSC5 Hard Disk Drive Tray: Use your finger to release the drive tray and then pull it out. Remove all jum pers on the hard disk and place it on the tray. Secure it with fo ur screws.
Page 34: Hsc5 Lvd Scsi Backpanel Board
1.6.3 HSC5 LVD SCSI Backpanel Board The HSC5 LVD SCSI hot-swap cage supports five 1-inch SCA SCSI hard drives in one channel. The SCA connector design allows for the addition and removal of SCSI drives without shutting down the system. Open...
Page 35: Hsc5 Jumpers And Connectors
Backpanel Features The backpanel board has the following major features: • “Hot-swap” feature that allows replacement of hard drives even when the system is still on. • Indicates hard disk drive failure through a front panel board LED on cage. •...
Page 36 Jumper Setting Function Short/Open Terminator Power Source Both from Backpanel and Host Only from Host SW1 & SW2 Reserved Connector Description SCSI 68-pin connector - Out Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Front panel LED connector (reserved) SCSI 68-pin connector - In Reserved CN10...
Page 37 Connector Description Power connector Reserved Slot 1 ID switch Slot 2 ID switch Slot 3 ID switch Slot 4 ID switch Slot 5 ID switch For HSC5 power loading requirement, please use independent power connectors to connect HSC5. If there is more than one connector on the same wire, those additional connectors should not be used.
Page 38 The power subsystem consists of two hot-swappable power supply module bays that allow the installation of two 337-watts power supply modules in a hot-swappable redundant configuration. A redundant power configuration enables a fully-configure system to continue running even if one power supply fails. The SV320 comes with one hot-swappable redundant power supply installed.
Page 39 Insert the power supply into the housing. Make sure that the power supply is properly inserted. Secure the power supply with a screw. Open...
Page 40 To remove a hot-swappable redundant power supply, please follow the steps as shown below. Using a flat-head screwdriver, turn the screw counter clockwise to loosen the power supply. Push the metal lock towards the power supply as shown below and gently pull out the power supply using the metal handle. The power supply subsystem should supply a minimum of 337-Watts...
Page 41 An additional external redundant fan can be installed behind the system housing. This allows the system to operate properly even though the internal housing fan failed. To install an external redundant fan: Open the front panel and remove the left panel of the housing. See section 1.4.1 for more information on opening the housing panels.
Page 42 Redundant Fan Screw Insert the fan cable into the peg hole and attach the cable to the motherboard. The fan can be connected to the motherboard fan connector. Open...
Page 43 The housing accommodates various motherboard sizes. You can rearrange the stand-offs on the motherboard plate to fit the board that you wish to install. Motherboard Align the motherboard holes to the pegs with the external ports facing the rear of the housing. Secure the board with eight screws. Open...
Page 44 To install an expansion card: 2. Remove an expansion slot bracket cover. Save the screw to secure the expansion card. 3. Align an expansion board with the open slot and insert the golden fingers into the expansion bus connector. 4. Secure the board with the screw. Open...
Page 45: O Verview
® Thank you for choosing AOpen DX37-U / DX37 Plus-U. The DX37-U / DX37 Plus-U is Intel Socket 370 motherboard (M/B) based on the ATX form factor featuring the VIA Apollo Pro266T chipset. As high performance chipset built in the M/B, the DX37-U / DX37 Plus-U ®...
Page 46: Chipset
® Supports single/dual Intel FC-PGA Pentium III (Both Coppermine & Tualatin are supported) 600MHz~1.26GHz with 100/133MHz FSB (Front Side Bus) designed for Socket 370 technology. Chipset ® Uses the high performance the VIA Apollo 266T chipset in DX37-U / DX37 Plus-U. This chipset contains the various controller inclusive 32-bit Accelerated Graphics Port (AGP), 32-bit PCI bus and 64-bit advanced high performance DRAM.
Page 47: Scsi On-Board (Dx37 Plus-U Only)
SCSI On-board (DX37 Plus-U only) The dual channel Adaptec 7899W chip host adapter delivers Ultra160/m SCSI data transfer rates which doubles the Ultra SCSI data transfer rate of up to 160MB/s. With two channels, it delivers a total of 320MB/s bandwidth. In addition, the AIC-7899 features a 66MHz, 64bit PCI interface that supports zero wait-state memory which also operates on 33MHz, 32bit PCI buses.
Page 48: Power Management/Plug And Play
Power Management/Plug and Play The DX37-U / DX37 Plus-U supports the power management function that confirms to the power-saving standards of the U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play which helps save users from configuration problems, thus making to system more user-friendly.
Page 49 Fan3 Connector AUX-IN CD-IN Fan2 Connecto PC 99 Back Panel Intel 82550 10/100 LAN Low ESR Capacitor Controller CPU1 Fan Connector AGP Pro Slot Dual CPU Sockets 32 Bit PCI Slot x 5 USB Connector CPU #2 CPU #1 CPU2 Fan Connector Fan1 Connecto ATX 20-pin Power Connector 4Mbit Flash BIOS...
Page 50 PC-1600/2100 DDR SDRAM Up to 4GB DIMM Socket x4 Socket 370 Intel Pentium III (Both Tualatin 32-bit PCI Slot x5 with 512K Cache & 100/133MHz Coppermine are System Bus supported) PCI Bus North Bridge VIA VT8653 Primary 33/66100 Channel IDE Drive x4 Secondary Channel AC’97 Link...
Page 51 The table below lists the different connectors or jumpers on the motherboard and their respective functions. Connector Function Internal buzzer Battery 20 pin ATX power supply connector 6 pin AUX power supply connector Rear USB ports 1 CPU1 Fan connector CN7-10 DIMM slots CN11...
Page 52 Connector Function CN33 68pin SCSI 160 channel A CNX2 Game port connector (16 pin) JP14 Clear CMOS PCI 1 to 5 32-bit PCI slot CPU 1 socket VIA Pro266T chipset (NB : VT8653) CPU 2 socket Intel 82550 LAN chipset VIA Pro266T chipset (NB : VT8233) Super IO Audio (AC97 Codec AD1885)
Page 53: H Ardware
This chapter describes jumpers, connectors and hardware devices of this motherboard. Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component. 1.Do not remove a component from its protective packaging until you are ready to install it.
Page 54 2.6.1 JP14 Clear CMOS You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. 2. Remove ATX power cable from connector PWR2. 3. Locate JP14 and short pins 2-3 for a few seconds. 4.
Page 55: Cpu Installation
2.6.2 CPU Installation CPU socket lever Pull up the CPU socket level and up to 90-degree angle. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper interface. Match Pin 1 and cut edge. Then insert the CPU into the socket.
Page 56: Cpu & System Fan Connector
2.6.3 CPU & System Fan Connector Plug in the CPU fan cable to the 3-pin CPU1 FAN and CPU2 FAN connector. If you have chassis fan, you can also plug it on System FAN (FAN2) or AUX FAN (FAN3) connector. FAN3 Connector +12V Sensor...
Page 57: Supported Cpu Type
2.6.4 Supported CPU Type 2.6.4 Supported CPU Type ® The DX37-U / DX37 Plus-U supports Intel Socket 370 Pentium III series CPU. Including the code name Tualatin 512K cache CPU for dual CPU configuration. Processor Name Processor Name CPU Package CPU Package Single Processor Pentium !!!
Page 58: Setting Cpu Voltage And Frequency
2.6.5 Setting CPU Voltage and Frequency Setting CPU Core Voltage This motherboard supports CPU VID function. The CPU core voltage will be automatically detected and the range is from 1.05V to 1.825V. It is not necessary to set CPU Core Voltage Setting CPU Frequency This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, no jumpers or switches are needed.
Page 59 CPU Core Frequency FSB Clock Ratio Pentium III 600E 600MHz 100MHz Pentium III 650E 650MHz 100MHz 6.5x Pentium III 700E 700MHz 100MHz Pentium III 750E 750MHz 100MHz Pentium III 800E 800MHz 100MHz Pentium III 850E 850MHz 100MHz 8.5x Pentium III 533EB 533MHz 133MHz Pentium III 600EB...
Page 60: Dimm Socket
2.6.6 DIMM Socket This motherboard has four 184-pin DIMM sockets that allow you to install PC1600 or PC2100 memory up to 4GB. DIMM 1 DIMM 2 DIMM 3 DIMM 4 Open...
Page 61 Please follow the procedure as shown below to finish memory installation. Make sure the DIMM module’s pin face down and match the socket’s size as depicted below. Pin 1 52 pins 40 pins Insert the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place.
Page 62 2.6.7 ATX Power Connector and AGP Pro Power Connector ® The DX37-U / DX37 Plus-U uses Intel SSI (Server System Infrastructure) type 24-pin ATX power connector. The 6-pin AGP Pro Power connector provides extra +5V and +3.3V power for AGP Pro VGA card. Make sure you plug in the right direction. +12V 5VSB PW-OK...
Page 63: Redundant Sps Monitoring Connector
This motherboard implements Redundant SPS monitoring connector to provide hardware monitoring signals. It is feasible to install an additional 337-watt power supply module (optional with AOpen Server Housing) in a hot swappable configuration. If any SPS failed, a signal will be sent to a hardware monitoring device.
Page 64: Ide And Floppy Connector
2.6.9 IDE and Floppy Connector Connect 34-pin floppy cable and 40-pin ATA66 or ATA33 IDE cable to floppy connector FDC and IDE connector IDE1, IDE2. Pin1 of cable is normally marked with red color. Be careful of the pin1 orientation. Wrong orientation may cause system damage. Primary Primary Master Slave (2nd)
Page 65 IDE1 is also known as the primary channel and IDE2 as the secondary channel. Each channel supports two IDE devices that make a total of four devices. In order to work together, the two devices on each channel must be set differently to Master and Slave mode. Either one can be the hard disk or the CDROM.
Page 66 This motherboard supports ATA33, ATA66 ATA100 IDE devices. Following table lists the transfer rate of IDE PIO and DMA modes. The IDE bus is 16-bit, which means every transfer is two bytes. Mode Clock Period Clock Cycle Time Data Transfer Rate Count PIO mode 0 30ns...
Page 67: Pin Ultra 160 Scsi Connector (Dx37 Plus-U Only)
2.6.10 68-pin Ultra 160 SCSI Connector (DX37 Plus-U only) The DX37 Plus-U provides two 68-pin Ultra Wide/Ultra 2/3 SCSI connectors for 16-bit or 16-bit differential SCSI devices. Disable SCSI Ch A SW1(3) Terminator Disable SCSI Ch B SW1(4) Terminator A Terminator B Terminator Open...
Page 68: Front Panel Connector
2.6.11 Front Panel Connector Attaching such as power LED, speaker, reset switch, power switch connector, etc.… to corresponding pins. The green cap on pin 19 & 20 is to disable Chassis Intrusion Switch, you may just take it off to able this function. 21 22 Ch ssis Intrusion Reset Switch...
Page 69: Wol (Wake On Lan)
2.6.12 WOL (Wake on LAN) To use Wake On LAN function, you must have a network card with chipset that supports this feature, and connect a cable from LAN card to motherboard WOL connector. The system identification information (probably IP address) is stored on network card and because there is a lot of traffic on the Ethernet, you need to install a network management software, such as ADM, for the checking of how to wake up the system.
Page 70 WOL Connector (Ethernet Card Side) WOL Connector (Motherboard Side) Note: These pictures are for example only, it may not exactly be the same motherboard. Open...
Page 71: Support 4 Usb Connectors
2.6.13 Support 4 USB Connectors This motherboard provides four connectors to connect USB devices, such as mouse, keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You can use proper cable to connect other USB connectors to the back panel or front panel of chassis.
Page 72: Scsi Led Connector (For Scsi/Raid Card, Dx37 Plus-U Only)
2.6.14 SCSI LED Connector (For SCSI/RAID Card, DX37 Plus-U Only) The 4-pin SCSI LED connector can be connected to a PCI SCSI control card activity LED connector. Read or write activity by devices connected to the SCSI card will transfer a signal to Front Panel and thus making the LED lighting up. SCSI Card Open...
Page 73: Cd/Aux Connector
2.6.15 CD/AUX Connector The AUX-IN connector is used to connect MPEG Audio cable from MPEG card to onboard sound. The CD-IN connector is used to connect CD Audio cable from CDROM or DVD drive to onboard sound. CD-IN (Black) AUX-IN (Gray) Connector Pin1...
Page 74: Pc99 Color Coded Back Panel
2.6.16 PC99 Color Coded Back Panel The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, serial ports COM1 and COM2, Printer, USB, RJ45 LAN. The view angle of drawing shown here is from the back panel of the housing. PS/2 Mouse SPP/ECP/EPP Print Port Connector Speaker Out...
Page 75: Support 10/100 Mbps Lan Onboard
2.6.17 Support 10/100 Mbps LAN onboard The South Bridge V8233 of VIA Apollo Pro266T chipset includes a fast Ethernet controller on chip. On the strength of Intel 82550 PHY on board, which is a highly-integrated Platform LAN Connect device, it provides 10/100M bps Ethernet for office and home use, the Ethernet RJ45 connector is located on the back panel.
Page 76: Low Esr Capacitor
2.6.18 Low ESR Capacitor The quality of low ESR capacitor (Low Equivalent Series Resistor) during high frequency operation is very important for stability of CPU power. The location of where to put these capacitors is another knowhow that requires experience and detail calculation. Open...
Page 77 Most of system had already configured by the manufacturer or the dealer. There is no need to run BIOS setup program when starting the computer unless you get a run setup program message. The setup program loads configuration values into the battery-backed nonvolatile memory called CMOS RAM. This memory area is not part of the system RAM.
Page 78 To enter Setup, press the DELETE key. You must press DELETE while the system is booting. This key does not work during any other time. The Setup Utility Main Menu appears: Open...
Page 79 The system supports two BIOS Utility levels: Basic and Advanced. If you are an advanced user, you may want to check the detailed configuration of your system. Detailed system configurations are contained in the Advanced Level. To view the Advanced Level, press The asterisk (*) mark indicates that the parameter appears only when you are in the Advanced Level.
Page 80: S Ystem I Nformation
The following screen appears if you select System Information from the Main menu: The System Information menu shows the current basic configuration of your system. The sections below explain the parameters. 3.2.1 Processor The Processor parameter specifies the type of processor currently installed in your system. The system supports Intel Pentium II and Pentium...
Page 81: Processor Speed
3.2.2 Processor Speed The Processor Speed parameter specifies the speed of the processor currently installed in your system. 3.2.3 CPU/SDRAM BUS Frequency This parameter specifies the currently FSB (Front Side Bus) frequency of the CPU/SDRAM. 3.2.4 Level 1 Cache This parameter specifies the first-level or the internal fast accessed memory (i.e., the memory integrated into the CPU) size, and whether it is enabled or disabled.
Page 82: Ide Primary Channel Master
3.2.8 IDE Primary Channel Master This parameter specifies the current configuration of the IDE device connected to the master port of the primary IDE channel. 3.2.9 IDE Primary Channel Slave This parameter specifies the current configuration of the IDE device connected to the slave port of the primary IDE channel. 3.2.10 IDE Secondary Channel Master This parameter specifies the current configuration of the IDE device connected to the master port of the secondary IDE channel.
Page 83: Serial Port 1
3.2.13 Serial Port 1 This parameter shows the serial port 1 address and IRQ setting. 3.2.14 Serial Port 2 This parameter shows the serial port 2 address and IRQ setting. 3.2.15 Parallel Port This parameter shows the parallel port address and IRQ setting. 3.2.16 PS/2 Mouse The BIOS utility automatically detects if there is a pointing device connected to your system.
Page 84: P Roduct I Nformation
The Product Information contains the general data about the system, such as the product name, serial number, BIOS version, etc. This information is necessary for troubleshooting (may be required when asking for technical support). The following shows how the Product Information screen appears: 3.3.1 Product Name This parameter specifies the official name of the system.
Page 85: System S/N
3.3.2 System S/N This parameter specifies the system’s serial number. 3.3.3 Main Board ID This parameter specifies the motherboard’s identification number. 3.3.4 Main Board S/N This parameter specifies the motherboard’s serial number. 3.3.5 System BIOS Version This parameter specifies the version of the BIOS utility. 3.3.6 SMBIOS Version This parameter specifies the version of the SMBIOS version.
Page 86: Disk Drive
Select Disk Drives to input configuration values for disk drives. The following screen shows the Disk Drives menu: 3.4.1 Floppy Drives To enter the configuration value for the first floppy drive, highlight the Floppy Drive A parameter. Press , key to view the options and select the appropriate value.
Page 87: Ide Drives
360KB 5.25" 1.2MB 5.25" 720KB 3.5" 1.44MB 3.5" 2.88MB 3.5" Follow the same procedure to configure floppy drive B. Choose “None” if you do not have a second floppy drive. 3.4.2 IDE Drives To configure the IDE drives connected to your system, select the parameter that represents the channel and port where the desired hard disk to configure is connected.
Page 88 The following screen appears if you select any of the IDE Drive parameters: Device Detection Mode Device Detection If you select “Manual”, you need to fill in all remaining field, such as Cylinder, Mode Head, and Sector on this selected item. If the item “Auto” is selected, the Auto (Default) items will remain “0”.
Page 89 Cylinder This parameter specifies the number of cylinders of your hard disk, and is automatically set depending on your Type parameter setting. Head This parameter specifies the number of heads of your hard disk, and is automatically set depending on your Type parameter setting. Sector This parameter specifies the number of sectors of your hard disk, and is automatically set depending on your Type parameter setting.
Page 90: O Nboard P Eripherals
The Onboard Peripheral Configuration allows you to configure the onboard communication ports and the onboard devices. Selecting this option displays the following screen: 3.5.1 Serial Ports 1 and 2 Serial Port 1 & 2 These parameters allow you to enable or disable serial Enabled (Default) ports 1 and 2.
Page 91 3.5.1.1 Base Address Base Address This item allows you to assign address and interrupt for the Serial Port 1: board serial port. 3F8h (Default) 3E8h 2E8h Serial Port 2: 2F8h (Default) 2E8h 3E8h 3.5.1.2 IRQ This function lets you assign an interrupt for serial ports 1 Serial Port 1: and 2.
Page 92: Parallel Port
3.5.2 Parallel Port Parallel Port This parameter allows you to enable or disable the parallel Enabled (Default) port. Disabled 3.5.2.1 Base Address Base Address This item allows you to assign address and interrupt for the 378h (Default) board serial port. 3BCh 278h 3.5.2.2 IRQ...
Page 93 appears on the screen. Check the parallel port address of the add-on card and change the address to one that does not conflict. 3.5.2.3 Operation Mode Operation Mode This item lets you set the parallel port mode. The mode EPP (Default) options are Standard, Bi-directional, EPP (Enhanced Parallel Bi-Directional Port) and ECP (Extended Parallel Port).
Page 94: Onboard Device Settings
3.5.2.4 ECP DMA Channel ECP Mode Use DMA This item becomes active only if you select Extended Capabilities Port (ECP) as the operation mode. It allows you 1 (Default) to assign DMA channel 1 or DMA channel 3 for the ECP parallel port function (as required in Windows 95).
Page 95 3.5.3.1 Floppy Disk Controller Floppy Disk This parameter lets you enable or disable the onboard floppy Controller disk controller. Enabled (Default) Disabled 3.5.3.2 IDE Controller IDE Controller Set this parameter to “Primary” to enable only the primary IDE Both (Default) controller;...
Page 96 Host This parameter lets you enable or disable the USB controller on Controller board. When enabled, it activates the USB function of the Enabled (Default) system. When disabled, it deactivates the function. Disabled 3.5.3.5 USB Legacy Mode USB Legacy Mode This parameter lets you enable or disable the USB controller on Enabled board.
Page 97 3.5.3.8 Onboard Ethernet Chip On-board This parameter allows you to enable or disable the onboard Ethernet Chip network feature. Enabled Disabled (Default) Open...
Page 98: P Ower M Anagement
The Power Management menu allows you to configure the system power-management feature. The following screen shows the Power Management parameters and their default settings: Open...
Page 99: Power Management Mode
3.6.1 Power Management Mode Power This parameter allows you to reduce power consumption. Management When this parameter is set to “Enabled”, you can configure the Mode IDE hard disk and system timers. Setting it to “Disabled” Enabled (Default) deactivates the power-management feature and its timers. Disabled 3.6.1.1 IDE Hard Disk Standby Timer Hard...
Page 100: Power Switch < 4 Sec
3.6.1.2 System Sleep Timer System Sleep This parameter sets the system to the lowest power-saving Timer mode after a specified period of inactivity. Any keyboard or Off (Default) mouse action or any activity detected from the IRQ channels 120, 110, 100…20, resumes system operation.
Page 101: System Wake-Up Event
3.6.3 System Wake-up Event The system wake-up event allows the system to resume operation when the modem ring indicator is enabled. 3.6.3.1 Modem Ring Indicator Modem Ring When “Enabled” any fax/modem activity wakes up the system Indicator from suspend mode. The default setting is “Disabled”. Enabled Disabled (Default) 3.6.3.2 PCI Power Management...
Page 102 Resume Day Resume Day This item is displayed when you enable the “RTC Timer” option. 1 to 31 Here you can specify what date you want to wake up the system. For example, setting to 15, the system will wake up on the 15 day of every month.
Page 103: Boot Option
This option allows you to specify your preferred setting for boot up. The following screen appears if you select Boot Options from the Basic Configuration menu: Open...
Page 104: Boot Sequence
3.7.1 Boot Sequence This parameter allows you to specify the boot search sequence during POST. • . The system checks this drive first. • . The system then checks this drive if it can not boot from the 1 specified drive. •...
Page 105: Silent Boot
3.7.3 Silent Boot Silent Boot This parameter enables or disables the Silent Boot function. Enabled (Default) When set to ”Enabled”, BIOS is in graphical mode and displays Disabled only an identification logo during POST and while booting. After booting the screen displays the operating system prompt (such as DOS) or logo (such as Windows 95).
Page 106: Memory Test
3.7.5 Memory Test Memory Test When set to ”Enabled”, this parameter allows the system to Enabled perform a RAM test during the POST routine. When set to Disabled (Default) “Disabled”, the system detects only the memory size and bypasses the test routine. 3.7.6 Release All Blocked Memory Release When set to “Enabled”, this parameter allows system to bypass...
Page 107: Date And Time.
The real-time clock keeps the system date and time. After setting the date and time, you do not need to enter them every time you turn on the system. As long as the internal battery remains good (approximately seven years) and connected, the clock continues to keep the date and time accurately even when the power is off.
Page 108: Date
3.8.1 Date Date Highlight the items on the Date parameter and press ww:mm:dd:yy to set the date following the weekday-month-day-year format. Valid values for weekday, month, day, and year are: • Weekday: Sun, Mon, Tue, Wed, Thu, Fri, Sat • Month: Jan, Feb, Mar, Apr, May, Jun, Jul, Aug, Sep, Oct, Nov, Dec •...
Page 109 The Setup program has a number of security features to prevent unauthorized access to the system and its data. The following screen appears if you select System Security from the Main menu: Open...
Page 110: Supervisor Password
3.9.1 Supervisor Password Supervisor This item can prevent unauthorized access to the BIOS utility. Password The “Present” setting allows you to set a setup password. None (Default) Present Enable the Supervisor Password parameter in the System Security menu by pressing the ENTER key. The Supervisor Password windows will appear as shown above.
Page 111: User Password
Press the ENTER key. Re-type the password to verify your first entry then press ENTER key again. Highlight the “Set or change password” option and press ENTER key. Press the ESC key to return the System Security screen. Press the ESC key to exit setup. The Exit Setup screen will appear. Choose “Yes”...
Page 112: Processor Serial Number
Write Protect Boot Sector Disables the write function only on the boot sector Hard Disk Drive Setting Description Normal Hard disk drive functions normally Write Protect All Sectors Disables the write function on all sectors Write Protect Boot Sector Disables the write function only on the boot sector 3.9.4 Processor Serial Number Processor...
Page 113 The system event log enables you to record and monitor events that occurs in your system like system temperature, fan stops, and others. This feature allows you to specify the appropriate settings for your system’s event handling. Selecting the option displays the following screen: Open...
Page 114: System Event Logging
3.10.1 System Event Logging This option allows you to record monitored events that occur during the operation of your system. 3.10.1.1 Event Logging Event Logging This item allows you to enable or disable the system event Enabled (Default) logging function. Disabled 3.10.1.2 Clear Event Logs Clear Event Logs...
Page 115: Events Control
3.10.1.4 Available Space for Event Logs Available Space The percentage of space that is still available for logging system for Event Logs events. 3.10.1.5 View Event Logs View Event Logs Opens the system event log file for viewing. 3.10.2 Events Control This parameter monitors the following events and logs them into the event log file if there is a change in status.
Page 116: Event Process
3.10.2.3 PCI PCI or Peripheral Component Interconnect is a 32-bit bus that Enabled (Default) can run at clock speeds of 33 MHz. This parameter monitors the Disabled activity of this bus when set to enabled. 3.10.3 Event Process 3.10.3.1 Action After Critical Event Action After This parameter allows you to select the action after BIOS finds a...
Page 117 Use this option to load the default settings for the optimized system configuration. When you load the default settings, some of the parameters are grayed-out with their fixed settings. These grayed parameters are not user-configurable. The following dialog box appears when you select Load Default Settings from the main menu: Select “Yes”...
Page 118 Use this option to disregard your changes to the BIOS and reload your previous settings. The following dialog box appears when you select Abort Settings Change from the main menu: Select “Yes” to disregard your changes and reload your previous settings. After reload, the main menu appears on screen. Select “No”...
Page 119: Settings For The Scsi Controller And All Devices
™ ™ The SCSISelect™ utility allows you to change SCSI controller settings without opening the system or changing jumpers. The table below lists the settings that you can change using the SCSISelect™ utility and the default value for each setting. Some settings apply globally to the SCSI controller and all SCSI devices on the bus.
Page 120: Individual Settings For Scsi Drives
BIOS Support for Int13 Extensions Enabled Support for Ultra SCSI Speed Disabled Individual Settings for SCSI Drives Item Default Initiate Sync Negotiation Maximum Sync Transfer Rate 160MB/sec. Enable Disconnection Send Start Unit SCSI Command * Initiate Wide Negotiation When to Use the SCSISelect™ Utility Use the SCSI Select utility if you need to do any one of the following: •...
Page 121 ™ ™ A screen message giving the option to access the SCSISelect™ utility appears after the BIOS and POST routine. To start the utility, press + A when the following message appears during power-on or system reset: Press <Ctrl> <A> for SCSISelect Utility! Your screen may show the key sequence as + <Hot Key>...
Page 122: Configuring Channel A
When the SCSI Select utility detects that the AIC-7899W SCSI controller is in the system, it displays the following Options menu: Adaptec AIC-7899W SCSISelect (TM) Utility v2.10 You have an AIC-7899W Bus:Device:Channel SCSI host adapter in your system. Move the cursor to the bus:device:channel of 02:09:A the one to be configured and press <Enter>...
Page 123 If you choose to configure Channel B, a similar SCSI Utility Screen will appear. The only difference is the I/O Port Address: A000h for Channel A A400h for Channel B Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7899 at Bus:02h Device:09h Channel: A Would you like to configure the host adapter, or run the SCSI disk utilities? Select the option and press <Enter>.
Page 124 Using and then press to make selections in the SCSISelect™ utility. Press at any time to return to the previous menu. You can press to toggle the display between color and monochrome modes. This feature may not work with some kinds of monitors. Open...
Page 125 The Configure/View Host Adapter Settings menu lists three settings under SCSI Bus Interface Definitions and three additional options. Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7896 at Bus:02h Device:09h Channel:A Configuration SCSI Bus Interface Definitions Host Adapter SCSI ID ………………………………..7 SCSI Parity Checking ………………………………Enabled Host Adapter SCSI Termination……………………..Enabled Additional Options Boot Device Options………….…………………Press <Enter>...
Page 126: 4.3.1 Host Adapter Scsi Id
Using to select a parameter. Press to display a pop-up menu with a list of possible settings for the parameter. Press at any time to return to the previous menu. SCSI controller default settings are marked with an asterisk (*) throughout the selection submenus. 4.3.1 Host Adapter SCSI ID This parameter allows you to change the host controller SCSI ID.
Page 127: Scsi Parity Checking
Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7899 at Bus:02h Device:09h Channel:A Configuration SCSI Bus Interface Definitions Host Adapter SCSI ID ……… ………… ……………….7 SCSI Parity Checking ……… ………… ……………...Enabled Host Adapter SCSI Termination……………………….Enabled Additional Options Boot Device Options………… ……… …..……….Press <Ente r>...
Page 128: Scsi Parity Checking
4.3.2 SCSI Parity Checking Select this option to enable or disable the SCSI parity checking function on the SCSI controller. The screen below displays the selections. The default setting is “Enabled”. The SCSI controller always checks parity when reading from the SCSI bus to verify the correct transmission of data from the SCSI devices.
Page 129: Boot Device Options
Arrow keys to move cursor, <Enter> to select option, <Esc> to exit (*=default) Using then press to select options. Press at any time to return to the previous menu. 4.3.3 Boot Device Options This parameter shows the target ID of your boot device. The default setting is 0 (zero). We recommend that you keep the default setting since most system applications run only in this setting.
Page 130: Bios Information Interrupt (Irq) Channel
4.3.4 Boot Channel Options This parameter lets you choosing boot the system from SCSI channel A or B first. The default setting is A (zero). We recommend that you keep the default setting since most system applications run only in this setting. Below is the Boot Device Configuration menu screen.
Page 131: Boot Scsi Id Options
4.3.5 Boot SCSI ID Options This parameter lets you choosing the SCSI ID of SCSI device to be a boot device. The default setting is 0 (zero). We recommend that you keep the default setting since most system applications run only in this setting. Below is the Boot Device Configuration menu screen.
Page 132: Boot Lun Number Options
4.3.6 Boot LUN Number Options Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7899 at Bus:02h Device:09h Channel:A Configursation SCSI Bus Interface Definitions Boot Devic e Conf iguration Host Adapter SC SI ID ………………………… ………7 Select SCSI peripheral from which to boo To view peripheral by ID# select "SCSI Disk Ut ilities"...
Page 133: Boot Lun Number
4.3.7 Boot LUN Number LUN (Logic unit number) can support more devices, like RAID box or RAID card. 4.3.7.1 SCSI Device Configuration This parameter allows you to configure details of each SCSI device on the SCSI bus. The screen shows a column of information for each SCSI ID, even if some SCSI IDs are not assigned to a device.
Page 134 Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 SCSI Device Configuration SCSI Device ID --------------------------------------------------------------------------------------------------------------- Sync Transfer Rate (MB/Sec).160.0 160.0 160.0 160.0 160.0 160.0 160.0 160.0 Initiate Wide Negotiation………Yes Enable Disconnection………….Yes Send Start Unit Command…….Yes Enable Write Back Cache…..…N/C -------------Options Listed Below Have NO EFFECT if the BIOS is Disabled------------- BIOS Multiple LUN Support…...No Include in BIOS Scan………..…Yes SCSI Device ID...
Page 135 4.3.7.2 Sync Transfer Rate This option determines the maximum synchronous data transfer rate that the SCSI controller can support. The SCSI controller supports rates up to the Fast Wide SCSI maximum of 80.0 MB per second. The default value is 80.0. In most cases, you can use the maximum value of 80.0.
Page 136 if permitted by the SCSI controller. When set to No, the SCSI device is not allowed to disconnect from the SCSI bus. The default setting is Yes. Keep this item set to Yes if two or more SCSI devices are connected to the SCSI controller. This can optimize SCSI bus performance. If only one SCSI device is connected to the SCSI controller, set this item to No to achieve better system performance.
Page 137: A Dvanced C Onfiguration O Ptions
Selecting the Advanced Configuration Options displays a screen as shown below. Do not change the settings of the items under this parameter unless it is absolutely necessary. Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7899 at Bus:02h Device:09h Channel:A Configuration Advanced Configuration Options SCSI Bus Interface Definitions Reset SCSI Bus at IC Initialization………………………………..Enabled Host Adapter SCSI ID …………………………………7...
Page 138: Host Adapter Bios
Using or to move between options, then press to display a pop-up menu with a list of options. Using to select an option, then press 4.4.1 Host Adapter BIOS This option enables or disables the SCSI controller BIOS. The default setting is Enabled. The SCSI controller BIOS must be enabled if you want the system to boot from a SCSI hard disk drive connected to the SCSI controller.
Page 139: Support Removable Disks Under Bios As Fixed Disks
See the section Disk Drives Over 1 GB” in this chapter, for more information on this option. This option should be left disabled for most operating systems except DOS. 4.4.4 Support Removable Disks Under BIOS as Fixed Disks This option allows you to control which removable-media drives are supported by the SCSI controller BIOS. This is only valid when the SCSI controller BIOS is enabled.
Page 140: Bios Support For Bootable Cd-Rom
4.4.5 BIOS Support for Bootable CD-ROM When enabled, this option allows you to use a bootable CD-ROM device to directly load an operating system. The default setting is Enabled. 4.4.6 BIOS Support for Int13 Extensions This option allows access to attached SCSI devices through BIOS Int13 functions. The default setting is Enabled. Open...
Page 141 When you select SCSI Disk Utilities from the Options menu, the SCSISelect™ Utility scans the SCSI bus and lists all SCSI devices installed on the SCSI bus. The list shows the individual SCSI IDs assigned to each device on the SCSI bus. Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 Scanning SCSI ID:0 : LUN Number:0 Arrow keys to move cursor, <Enter>...
Page 142 Adaptec AIC-7899 SCSISelect (TM) Utility v2.10 AIC-7899 at Bus:02h Device:09h Channel:A Select SCSI Disk and press <Enter> SCSI ID #0: No device SCSI ID #1: No device SCSI ID #2: No device SCSI ID #3: No device SCSI ID #4: No device SCSI ID #5: No device...
Page 143: Format Disk
4.5.1 Format Disk The Format Disk utility performs a low-level format on disk devices. Most SCSI disk devices are preformatted and do not need to be formatted again. The Adaptec Format Disk utility is compatible with the vast majority of SCSI disk drives. Run it on hard disk drives or removable-media drives that were previously used with a non-Adaptec SCSI controller.
Page 144: Extended Translation
4.6.1 Extended Translation Adaptec SCSI controllers have always supported the full range of disk drive capacities under all major operating systems. As disk drives have recently grown beyond 1 GB in formatted capacity, they have run up against the DOS 1024-cylinder limit. To continue its support for all SCSI disk drive capacities under DOS, Adaptec has included an extended translation scheme for the AIC-7896 SCSI controllers.
Page 145: With Dos 5.0 And Above
4.7.1 with DOS 5.0 and above NetWare 386 (version 3.0 and above) and some versions of UNIX that do not share the 1024 cylinder limit of DOS do not require extended translation to support large disk drives and should not be enabled. 4.7.2 drives with mixed partitions Use standard translation (not extended translation) on drives formatted with two or more partitions for different operating systems.
Page 146 AGP uses both rising and falling edge of the 66MHz clock, for 2X AGP, the data transfer rate is 66MHz x 4byte x 2 = 528MB/s. AGP is now moving to 4X mode, 66MHz x 4byte x 4 = 1056MB/s. AOpen is the first company to support 4X AGP motherboards by both AX6C (Intel 820) and MX64/AX64 (VIA 694x), started from Oct 1999.
Page 147 A disc bundled with AOpen motherboard product, there are motherboard drivers, Acrobat Reader for online manual and other useful utilities. Unlike ACPI, BIOS controls most APM power management functions. AOpen Suspend to Hard Drive is a good example of APM power management. ATA/66 uses both rising edge and falling edge but doubles UDMA/33 transfer rate.
Page 148 BIOS is a set of assembly routine/program that reside in EPROM Flash ROM. BIOS controls Input/output devices and other hardware devices of motherboard. In general, to provide hardware independent portability, operation system and drivers is required to access BIOS without directly access hardware devices. The traditional PIO (Programmable I/O) IDE requires the CPU to involve in all the activities of the IDE access including waiting for the mechanical events.
Page 149 Flash ROM can be re-programmed by electronic signals, but the interface technology is different. Size of EEPROM is much smaller than flash ROM, AOpen motherboard uses EEPROM for jumper-less and battery-less design. Traditional motherboard stores BIOS code in EPROM. EPROM can only be erased by ultra-violet (UV) light. If BIOS has to be upgraded, you need to remove EPROM from motherboard, clear by UV light, re-program, and then insert back.
Page 150 Flash ROM can be re-programmed by electronic signals. It is easier for BIOS to upgrade by a flash utility, but it is also easier to be infected by virus. Because of increase of new functions, BIOS size is increased from 64KB to 256KB (2M bit). AOpen AX5T is the first board to implement 256KB (2Mbit) Flash ROM.
Page 151 FSB Clock means CPU external bus clock. CPU internal clock = CPU FSB Clock x CPU Clock Ratio See SMBus. P1394 (IEEE 1394) is a standard of high-speed serial peripheral bus. Unlike low or medium speed USB, P1394 supports 50 to 1000Mbit/s and can be used for video camera, disk and LAN.
Page 152 SDRAM DIMM that supports 100MHz CPU bus clock. SDRAM DIMM that supports 133MHz CPU bus clock. A file format for electronic document, PDF format is independent from platform, you can read PDF file under Windows, Unix, Linux, Mac … with different PDF reader. You can also read PDF file by web browser such as IE and Netscape, note that you need to install PDF plug-in first (Included in Acrobat Reader).
Page 153 DIMM and operates at 3.3V. AOpen is the first company to support dual-SDRAM DIMMs onboard (AP5V), from Q1 1996 SIMM socket is only 72-pin, and is only single side. The golden finger signals on each side of PCB are identical. That is why it was called Single In Line.
Page 154 SMBus is also called I2C bus. It is a two-wire bus developed for component communication (especially for semiconductor IC). For example, set clock of clock generator for jumper-less motherboard. The data transfer rate of SMBus is only 100Kbit/s, it allows one host to communicate with CPU and many masters and slaves to send/receive message.
Page 155 NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements. VCM increases memory bus efficiency and performance of any DRAM technology by providing a set of fast static registers between the memory core and I/O pins. Using VCM technology results in reduced data access latency and reduced power consumption.
Page 156 Start Turn off the power and unplug the AC power cable, then remove all of the add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and printer. Make sure if all jumper settings are correct. Clear CMOS Next Open...
Page 157 Continue Install the VGA card. Then connect your monitor and keyboard. Turn on the power and check if the power supply and CPU fan work properly. The problem is probably caused by power supply or motherboard failure Next Please contact your reseller or local distributor for repairing.
Page 158 Continue Perhaps your VGA card Check if there is display? or monitor is defective. Press <Ctrl> and <Alt> key at the same time, hold them and then press <Del> to reboot the system. It is very possible that your Check if the system keyboard is defective.
Page 159 Continue During system rebooting, press <Del> to enter BIOS setup. Choose “Load Setup Default”. Turn off the system and re-connect IDE cable. The problem should be Check if the system can caused by the IDE cable reboot successfully? or HDD itself.
Page 160 Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us.
Page 161 News Group: Your problem probably had been answered by our support engineer or professional users on the news group. http://www.aopen.com/tech/newsgrp/default.htm Contact Distributors/Resellers: We sell our products through resellers and integrators. They should know your system configuration very well and should be able to solve your problem more efficiently than us.
Page 162 Be able to join the discussions of web-based news groups. AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or companies. Further, AOpen will not disclose any of information you submitted under any conditions. Please consult our online privacy policy further information on our company policy.
Page 163 Please do not hesitate contact us if you have any problem about our products. Any opinion will be appreciated. America Pacific Rim Europe AOpen America Inc. AOpen Inc. AOpen Computer b.v. Tel: 886-2-3789-5888 Tel: 31-73-645-9516 Tel: 1-510-498-8928 Fax: 886-2-3789-5899 Fax: 31-73-645-9604...

This manual is also suitable for:

Fortress 7700 Fortress 7900

AOpen DX37PU-OL-E0112B User Manual

Chapter 1 Housing Instruction (Sv320)

Chapter 2 Hardware Installation

Chapter 3 Bios Setup Utility

Chapter 4 Scsiselect™ Utility (Dx37 Plus-U Only)

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AOpen DX37PU-OL-E0112B

Summary of Contents for AOpen DX37PU-OL-E0112B

This manual is also suitable for:

Table of Contents
