Electrical connection

7
Electrical connection
7.1

Connection conditions

7.1.1
Terminal assignment
Terminal assignment 4-wire: 4-20 mA HART (90 to 253 V
 5
Terminal assignment 4-wire: 4-20 mA HART (90 to 253 V
1
Connection 4-20 mA HART (active): terminals 3 and 4
2
Connection supply voltage: terminals 1 and 2
3
Terminal for cable screen
20
2
1
Levelflex FMP53 PROFIBUS PA
)
AC
3
)
AC
A0036519
