Endress+Hauser Levelflex FMP53 Brief Operating Instructions page 28

Electrical connection
7.2.3 Plug-in spring-force terminals
In the case of devices without integrated overvoltage protection, electrical connection is via
plug-in spring-force terminals. Rigid conductors or flexible conductors with ferrules can be
inserted directly into the terminal without using the lever, and create a contact automatically.
 9 Dimensions: mm (in)
To remove cables from the terminal:
1. Using a flat-blade screwdriver ≤ 3 mm, press down on the slot between the two terminal
holes
2. while simultaneously pulling the cable end out of the terminal.
7.2.4 Closing connection compartment cover
1. Screw back firmly connection compartment cover.
28
3 mm
2,5 Nm
2.
Levelflex FMP53 PROFIBUS PA
1. 2.
≤ 3 (0.12)
1.
A0013661
A0021491
Endress+Hauser
