Levelflex FMP53 PROFIBUS PA
Block diagram PROFIBUS PA / FOUNDATION Fieldbus
7
Block diagram PROFIBUS PA / FOUNDATION Fieldbus
1
Cable screen; observe cable specifications
2
Connection PROFIBUS PA / FOUNDATION Fieldbus
3
Measuring device
4
Switch output (open collector)
Endress+Hauser
2
1
3
+
1
I
-
2
+
Y
3
-
4
4
Electrical connection
A0036530
23
