Multiple data connections
If you want to have different types of connections running at the same time, you can build
connection packages with the connections you want, using filters to determine which traffic
should use which connection type.
Type of traffic (e.g. UDP, TCP)
Type of Service (Quality of Service)
IP address
Port numbers
IP security used (IPSec SPI)
You then have to set up the following:
• Create a new package. See the next section To create a shared connection package.
• Add connections to the package.and select a predefined filter for each connection.
• Optional: Change the APN for the package. See To change the APN for a connection
package on page 80.
Example: You want to be able to send email while making a live video transmission with your
EXPLORER 710:
You build a new package containing 2 connections:
1: A 256 kbps streaming connection (for your video transmission). Select the UDP
filter.
2: A Standard connection (for email etc.). Select "No filter".
When you have started this connection package, your video input to the
EXPLORER 710 terminal is now automatically routed to the 256 kbps streaming
connection. All other traffic is routed to the Standard data connection.
98-140012-H
Connection package
Traffic flow
filters
Connection type 1
Streaming 256
UDP filter
Connection type 2
Standard
No filter
To set up your data connection packages
Chapter 4: To use the web interface
Streaming 256 E.g. video
connection streaming
Standard IP
E.g. email and
connection
web browsing
