COBHAM EXPLORER 710 User Manual page 168

Parameter Values
<protocol <protocol
number> number>
<source address <source address
and subnet and subnet
mask> mask>
<source port <source port
range> range>
<state> 0
1
<Traffic Class> 1
3
<Transfer delay> 0
500
4000
98-140012-H
Meaning
This number is uniquely assigned for the protocol being used. TCP is set to
6, and UDP is set to 17. The protocol number determines which protocol is
used by the traffic flow filter (0-255).
This is an IPv4 IP address and subnet mask (0.0.0.0.0.0.0.0 to
255.255.255.255.255.255.255.255). The first four numbers are the IP
address and the last four numbers are the subnet mask.
Source port range in the form From.To.
See <destination port range> for example.
Deactivate.
Activate.
Streaming (not available for M2M subscription).
Standard data (Background).
0 ms, error correction is determined by the network
500 ms, error correction is disabled
4000 ms, error correction is applied
AT commands
Appendix B: Command reference
159
