Section 5: Maintenance
5. To start the display test, press the ENTER key. There are three parts to the display test. Each
time the ENTER key or the navigation wheel is pressed, the next part of the test sequence is
selected. The test sequence is as follows:
▪
Checkerboard pattern and the indicators that are on during normal operation
▪
Checkerboard pattern (alternate pixels on) and all the numeric indicators (which are not used)
are illuminated
▪
Each digit and adjacent indicators are sequenced; all the pixels of the selected digit are on
6. When finished, abort the display test by pressing the EXIT (LOCAL) key. The instrument returns
to the FRONT PANEL TESTS menu. Continue pressing the EXIT (LOCAL) key to exit out of the
menu structure.

Upgrading the firmware

You can load a newer or older version of firmware to the instrument. The process takes about five
minutes.
To load the firmware, you can use a USB flash drive or select a file from a computer.
From the front panel, you must use the USB flash drive. Make sure the USB flash drive is empty
except for the firmware file.
From the web interface, Test Script Builder, or remote interface, you can select the file from the
computer.
Firmware files are available for download from the
(tek.com/product-support) in the category "Software." After downloading the file, unzip the file. The file
with the extension .x is the firmware file.
Disconnect the input and output terminals before you upgrade or downgrade.
Do not remove power from the instrument or remove the USB flash drive while an upgrade or
downgrade is in progress. Wait until the instrument completes the procedure and shows the
opening display. If you are upgrading an instrument with no front panel (NFP), the LAN and
1588 LEDs on the front panel blink in unison during the upgrade and stop when the upgrade
is complete.
Do not initialize or reset TSP-Link before starting the upgrade.
If you are loading an older version, check the release notes and verify that the version of
firmware you are loading is compatible with your hardware.
Before starting the upgrade, turn the instrument power off, wait a few seconds, then turn the
instrument power on.
