Section 3: Instrument description
Deleting USER TESTS menu entries
You can use the following function to delete an entry from the front-panel USER TESTS menu:
display.loadmenu.delete(displayname)
Where:
displayname
The following programming example removes the entry named Part1 from the front-panel USER
TESTS menu:
display.loadmenu.delete("Part1")

Running a test from the front panel

To run a user, factory, or script test from the front panel:
1. Press the LOAD key to display the LOAD TEST menu.
2. Select the USER, FACTORY, or SCRIPTS menu item.
3. Position the blinking cursor on the test to be run and press ENTER or the navigation wheel.
4. Press the RUN key to run the test.

Connecting the USB flash drive

The 2600B supports flash drives that comply with USB 2.0 standards and USB 1.0 and 1.1 standards.
You can save data to the USB flash drive from the front panel, or you can create a script to save data
to the USB flash drive.
To connect the USB flash drive, plug the USB flash drive into the USB port on the front panel of the
instrument, shown in the figure below.
3-34
Name to delete from the menu.
Figure 16: USB port
Series 2600B System SourceMeter® instrument User's Manual
2600BS-900-01 Rev. A / August 2021
