Series 2600B System SourceMeter® instrument User's Manual
smuX.source.offlimiti is ignored and the effective current limit depends on what the channel is
sourcing when it is turned off. If the channel is sourcing:
•
Voltage: The current limit is determined by smuX.source.limiti.
•
Current: The current limit is determined by the greater of smuX.source.leveli or 10 percent
of smuX.source.rangei.
Contact check commands
The following table summarizes the contact check commands. For a more complete description of
these commands, refer to the "TSP command reference" section of the Series 2600B
Reference Manual.
Basic contact check commands
Command
flag = smuX.contact.check()
rhi, rlo = smuX.contact.r()
smuX.contact.speed = speedSetting
smuX.contact.threshold = rvalue
Contact check programming example
The following programming example illustrates the setup and command sequence for a typical
contact check measurement. These commands set the contact check speed to fast and the threshold
to 100 Ω. Then, a contact check measurement against the threshold is made. If it fails, a more
accurate contact check measurement is made, and the test is aborted. Otherwise, the output is
turned on, and the test continues.
-- Restore defaults.
smua.reset()
-- Set contact check speed to fast.
smua.contact.speed = smua.CONTACT_FAST
-- Set the contact check threshold to 100 ohms.
smua.contact.threshold = 100
-- Check contacts against threshold.
if not smua.contact.check() then
-- Set speed to slow.
smua.contact.speed = smua.CONTACT_SLOW
-- Get aggregate resistance readings.
rhi, rlo = smua.contact.r()
-- Return contact resistances to the host.
print(rhi, rlo)
-- Terminate execution.
exit()
end
-- Turn output on and continue.
smua.source.output = smua.OUTPUT_ON
2600BS-900-01 Rev. A / August 2021
Description
Determine if contact resistance is lower than threshold.
Measure the aggregate contact resistance.
Set speedSetting to one of the following:
▪
0 or smuX.CONTACT_FAST
▪
1 or smuX.CONTACT_MEDIUM
▪
2 or smuX.CONTACT_SLOW
Set resistance threshold for the contact check function.
Section 4: Operation
4-15
