Series 2600B System SourceMeter® instrument User's Manual
Section 4: Operation
Figure 33: Model 2634B, 2635B, or 2636B safety shield for hazardous voltage test circuit
connections
1 Protective earth (safety ground)
2 Equivalent schematic
3 Metal safety shield
4 Device under test (DUT)
2600BS-900-01 Rev. A / August 2021
4-19
