Section 3: Instrument description
The string displays the same information as the web interface. Commas separate the fields. The
fields output in the following order:
•
Received time (UTC time)
•
Event ID
•
From (Sender)
•
HWDetect / version
•
Domain
•
Sequence number
•
Timestamp (PTP time)
•
Epoch (from 1588)
•
Flags
•
Data
See the table in
To generate log traffic, send the code:
local id = 1
lan.trigger[id].ipaddress = lan.status.ipaddress
lan.trigger[id].connect()
for domain = 1, 255 do
print(domain)
lan.lxidomain = domain
lan.trigger[id].assert()
delay(1)
end

Help

The help page in the web interface provides basic help for the web interface, a glossary of terms, and
a link to licenses for the virtual front panel, firmware upgrade tool, and TSB Embedded.
3-44
Logging LAN trigger events in the event log
Series 2600B System SourceMeter® instrument User's Manual
(on page 3-41) for detailed descriptions.
2600BS-900-01 Rev. A / August 2021
