Section 3: Instrument description
Menu selection
SCRIPT
- LOAD
- SAVE
SETUP
- SAVE
- RECALL
- POWERON
GPIB
- ADDRESS
- ENABLE
LAN
- STATUS
- CONFIG
- APPLY_SETTINGS
- RESET
- ENABLE
RS232
- BAUD
- BITS
- PARITY
- FLOW-CTRL
- ENABLE
TSPLINK
- NODE
- RESET
UPGRADE
DISPLAY
- TEST
- NUMPAD
DIGOUT
- DIG-IO-OUTPUT
- WRITE-PROTECT
- LEGACY-MODE
BEEPER
- ENABLE
- DISABLE
LINE-FREQ
- 50Hz
- 60Hz
- AUTO
SYSTEM-INFO
- FIRMWARE
- SERIAL#
- CAL
- MEMORY-USAGE
RESET-PASSWORD
3-14
Series 2600B System SourceMeter® instrument User's Manual
Description
Saves and recalls user scripts
Loads scripts into nonvolatile memory
Saves scripts
Saves and recalls user and factory setup options
Saves user setup options
Recalls user setup options
Sets the configuration used during startup
Configures the GPIB interface options
Configures the address for the GPIB interface
Enables and disables the GPIB interface
Configures the local area network (LAN)
Displays LAN connection status
Configures the LAN IP address and gateway
Applies changes made using the CONFIG menu
Restores the default settings
Enables and disables the LAN interface
Controls the options for the RS-232 interface
Sets the baud rate
Configures the number of bits
Sets the parity
Configures the flow control
Enables and disables the RS-232 interface
Configure the instrument in a TSP-Link
Selects the instrument node identifier
Resets the TSP-Link network
Upgrades the firmware from a USB flash drive
Accesses display functions
Runs the display test
Enables and disables the numeric keypad
Controls digital outputs
Selects the digital I/O values
Write-protects specific digital I/O lines
Sets digital I/O to work like an older
SourceMeter instrument
Controls the key beeps
Enables the key beeps
Disables the key beeps
Configures the line frequency
Set the line frequency to 50 Hz
Set the line frequency to 60 Hz
Enables automatic line-frequency detection during
start up
Displays the system information
Displays the version of firmware installed
Displays the serial number of the unit
Displays the last calibration date
Displays memory usage in percentage
Resets the system password
For more information, see:
Series 2600B Reference Manual,
"Manage scripts"
Series 2600B Reference Manual, "Saved
setups"
Series 2600B Reference Manual, "Remote
communications interfaces"
Series 2600B Reference Manual, "LAN
communications"
Series 2600B Reference Manual, "Remote
communications interfaces"
®
network Series 2600B Reference Manual,
"TSP-Link system expansion interface"
Upgrading the firmware
Front-panel tests
See Numeric entry method in
value (on page 3-19)
Series 2600B Reference Manual, "Digital
I/O"
Beeper (on page 3-21)
Line frequency configuration
System information
Series 2600B Reference Manual,
"Password management"
2600BS-900-01 Rev. A / August 2021
(on page 5-4)
(on page 5-3)
Setting a
(on page 2-4)
(on page 2-4)
