Chapter 2: Prerequisites

Electrical Requirements

A dedicated electrical outlet is required. Minimum requirements for an outlet
is a 15 Amp circuit breaker or fuse for models rated at 115V (60 Hz) or an 8
Amp circuit breaker or fuse is required for 230V (50/60 Hz) models. 115V
models are equipped with a 15 Amp NEMA 5-15P plug. 230V models are
available with a NEMA 6-15P plug for use in the United States, a PS 1363
plug for use in the United Kingdom, a CEE 7/7 plug for use in Europe or a
CHI-10P plug for use in China. It may be necessary to remove the plug and
install a different plug to match the available receptacle if one of these
models does not meet your needs.

Location and Exhaust Requirements

The RapidVap Vertex Evaporator must be located within a fume hood if
!
hazardous or flammable solvents are used. In all cases, regardless of the
solvent used, it is recommended that the exhaust hose is vented into a fume
hood or other laboratory ventilation device.

Nitrogen Supply Requirements

The 1/4" I.D. hose on the rear of the RapidVap Vertex Evaporator should be
attached to a regulated source of nitrogen or other suitable gas. Pressure
must NOT exceed 80 psi. The nitrogen supply must be capable of 6.5 CFM
flow rate. A suitable barb or compression fitting must be supplied by the
user.

Space Requirements

Refer to Appendix B: RapidVap Vertex Evaporator Dimensions for
dimensional drawings of the RapidVap Vertex Evaporator.

Tools Required

Common hand tools are required to set up the RapidVap Vertex Evaporator.
A screwdriver or 5/16" socket is needed to attach hose clamps. A tubing
cutter or knife is needed to shorten exhaust hoses.
