Appendix A: RapidVap Vertex Evaporator Components

RapidVap Vertex Evaporator Components
Item Quantity
1 5
2 1
3 1
4 1
5 2
6A 1
6B 1
7 1
8A 1
8B 2
9 1
10 1
11 1
12 5
13 1
14 1
15 1
26
Part No.
7320400 Manifold
7323700 Blower
7353300 Temperature Sensor Lower
7325100 Over Temperature Cut Out
1544600 Inlet Fitting
7322200 Control Valve 115V
7322201 Control Valve 230V
3823803 Power Supply
1289310 Circuit Breaker 10A (115V)
1289306 Circuit Breaker 6A (230V)
1302300 Power Switch
Label – Control Panel
7321400
7321900 Pressure Regulator
Valve – Toggle
7322500
7323100 PCB
7323000 LCD
7355301 Temperature Sensor Upper
Product Service 1-800-522-7658
Description
