XS Controller - USB Functions
Step 4:
This is the Configure Screen. From here push
HISTORY (Button 4) to go to the next screen.
>CONFIGURE<
PASSWORD
RELAYS
HISTORY
FLOW SW
Step 5:
This is the Configure History Screen. From here
push SAVE FORMAT (Button 4) to go to the next
screen.
>CONFIGURE HISTORY<
INTERVAL
W/M HOUR
DELAY
SAVE FORMAT
Step 6:
Set the value of the HISTORY SAVE FORMAT
by using the arrow keys. Then press ENTER to
confirm and go to the previous screen.
>CONFIGURE HISTORY<
HISTORY SAVE FORMAT
INTERVAL
W/M HOUR
--> WEB ADVANTAGE
DELAY
PRESS UP/DOWN KEYS TO CHANGE
SAVE FORMAT
PRESS ENTER TO ACCEPT
Note: WebAdvantage format is required for
uploading history to WebAdvantage for cloud
storage and graphing.
Separated format if using a database software
like Excel.
Press SET UP RUN to return to the RUN
screen.
Step 7:
Remove USB drive and re-insert to initiate the
USB DRIVE DETECTED pop-up window. Repeat
Step 1 from section Exporting Log Data.
MegaTron Quick Steps
CONTRAST
TEMP SCALE
NETWORK
SYS INFO
FACTORY
Change to Comma
Uploading data to WebAdvantage
If the controller does not have a communications card you
can purchase WEBADV-XSCLOUD storage of your unit's
history. This one-time fee per controller allows the XS
history to be stored on WebAdvantage for using custom
graphing and multiple user internet access. Contact
Advantage Controls or
with your unit's serial number to learn more.
After an XS is set-up for cloud storage, follow these steps:
1. Login to the secure web server:
https://webadvantage.online
2. Locate the controller you have data for and click
Reports
3. Click History Upload on the left
4. Click Choose File and select the file you exported.
5. Click Submit and the data will upload
6. You will now be able to view reports and history
data once completed.
Upgrading Firmware
To upgrade the firmware on your XS, copy the updated
software version to a USB drive. The file name should
be "firmware.bin" With the controller powered up, plug
the USB drive into the XS USB port. The USB DRIVE
DETECTED pop-up window will appear. If a password is
in the unit, the USB will ask for it.
Select --> Update Firmware by using the Arrow buttons.
Then press ENTER.
XS Controller
SYS1: Towers 1-4
USB DRIVE DETECTED
COND:
--> Update Firmware
PRESS UP/DOWN KEYS TO CHANGE
PRESS ENTER TO ACCEPT
pH: 3.2
ORP: 548
3 ALARMS!
Friday, February 6, 2015
Warning:
Do not remove power or USB during
updating. It may take a few minutes to complete. Once
the first update is complete, power off and remove USB.
Wait 20-30 seconds to power back on and reinstall the
USB after the RUN screen appears and load the firmware
a second time.
