7.4 Contrast
This menu is used to adjust the contrast of the display.
7.5 Network
The Network menu is used when a controller is being remotely communicated with either a local network
connection or over the internet on the Web Advantage server.
>NETWORK<
IP Addr: 192.168.001.006
Subnet: 255.255.255.000
Gateway: 192.168.001.253
DNS: 192.168.1.238
ACI Srvr: connect.webadvantage.online:443
MAC: E4.38.F2.00.01.3C
DHCP: ENABLE
DIAGNOSTICS
SETTINGS
>CONFIGURE NETWORK<
IP ADDRESS
IP MASK
GATEWAY
SERVER
HTTP LOCAL
7.8 System Information
System information will identify the version of firmware installed in the controller along with the controller's
serial number.
8. History
The onboard history allows for viewing the history of the mA readings, relay activations, key-pad activity,
calibrations, flow meter hourly and daily logs and alarms for each system present. It is also where Notepad
data is entered and reviewed. An initial overview page is displayed showing your current sample interval, the
calculated number of days the unit can keep probe history for before losing the oldest. The number of sensor
samples and relay/alarm events and Notepad entries currently stored is also displayed.
NETWORK - This menu is used for setting up the
remote WebAdvantage communications and is
covered in a separate manual.
http://www.advantagecontrols.com/downloads/pdf/M-WebAdvantage.pdf
Note: The Network card must be RESET after making any
changes to Network setting in order to save changes and
reset communications.
WIFI
WIFI / DHCP - Enable or disable if available.
DHCP
SETTINGS - This menu is used to configure a variety
RESET
of extended network options.
WIFI NETWORK - This menu is used for choosing the
local wifi network and setting the password. This is
WIFI NETWORK
covered more in a separate manual.
HTTP REMOTE
https://www.advantagecontrols.com/downloads/quicksteps/QS-
MegaTronXS-MT_H_WiFi.pdf
FTP
Note: Some choices may not be available if DHCP or WIFI
are disabled in previous NETWORK menu.
