Overview; Waypoint Ac Reference Chart; Specifications; Installation Instructions - Altronix WayPoint10A Installation Manual

WayPoint Outdoor Power Supplies provide 24VAC or 28VAC distributed via one or two output(s) for powering
CCTV cameras, heaters and other video accessories.
Altronix
Model Number
WayPoint10A
WayPoint17A
WayPoint30A
Agency Listings:
• CE European Conformity.
Input:
• Input: 115VAC, 50/60Hz or 230VAC, 50/60Hz.
Output:
• Output options:
a. 24VAC or 28VAC.
b. Both 24VAC and 28VAC.
Visual Indicators:
• Individual power output LED indicators.
• Illuminated master power switch with
built-in circuit breaker.
Unit should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Remove back plane from enclosure prior to mounting (do not discard hardware).
2. Mark and drill desired inlets on the enclosure to facilitate wiring (Fig. 1, pg. 3).
3. Mount unit in desired location.
Wall mount:
Pole Mount:
4. Mount back plane to enclosure with hardware.
5. Set the input voltage selector switch for 115VAC or 230VAC operation (Fig. 2, pg. 4, Fig. 3, pg. 5, Fig. 4, pg. 6)
6. To facilitate wire entry utilize weather tight NEMA 4 rated connectors, bushings and cable.
7. Set illuminated master power disconnect circuit breaker to the (OFF) position
(Fig. 2, pg. 4, Fig. 3, pg. 5, Fig. 4, pg. 6).
8. Connect unswitched AC power (115VAC/230VAC 50/60 Hz) to terminals marked [L, G, N]
(Fig. 2, pg. 4, Fig. 3, pg. 5, Fig. 4, pg. 6).
Wire gauge range of connectors is 14 AWG to 11 AWG (1.6 mm to 2.5 mm diameter).
9. Set illuminated master power disconnect circuit breaker to the (RESET/ON) position
(Fig. 2, pg. 4, Fig. 3, pg. 5, Fig. 4, pg. 6).
- 2 -

WayPoint AC Reference Chart:

Total Output
Output Voltage
24VAC
28VAC
24VAC and 28VAC
24VAC
28VAC
24VAC and 28VAC
24VAC
28VAC
24VAC and 28VAC

Installation Instructions:

Mount unit in desired location. Mark and drill holes to line up with the top and bottom
hole of the enclosure flange. Secure enclosure with appropriate fasteners (e. g. screws
and anchors; bolts and locking nuts, etc.) that are compatible with mounting surface and
are of sufficient length/construction to ensure a secure mount (Fig. 5, pg. 7).
Refer to Fig. 6 - 10, pg. 7) .

Overview:

Fuse
Current Output
(Power) Ratings
4A
3.5A 5A/250V
3.5A
7.25A
6.25A 10A/250V
6.25A
12.5A
10A 15A/32V
10A

Specifications:

Features:
• Surge suppression.
• Spare fuses included.
Accessories:
• Optional PMK1 Pole Mount Kit simplifies installation
of outdoor units.
Enclosure:
• NEMA 4/4X, IP66-11 Rated enclosure for
outdoor use.
• Enclosure Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.074mm x 287.274mm x 141.986mm)
Input Current Draw
115VAC 230VAC
50/60Hz 50/60Hz
1.2A 0.7A
1.7A 1.0A
3.5A 2.0A
WayPoint AC Series Installation Guide
Product
Weight
10.3 lbs.
13.1 lbs.
14.1 lbs.
