Altronix WayPoint-307A Manual

This Altronix Outdoor Power Supply provides 24VAC or 28VAC distributed via two outputs for powering CCTV
Cameras, heaters and other video accessories.
• CE Compliant.
• Input: 277VAC, 60Hz, 1.75 amp.
• Output options:
a. 24VAC @ 12.5 amp max.
b. 28VAC @ 10 amp max.
c. Both 24VAC and 28VAC not to exceed 10 amp max.
• Output fuses rated @ 15A 32V.
Unit should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Remove back plane from enclosure prior to mounting (do not discard hardware).
2. Mark and drill desired inlets on the enclosure to facilitate wiring (Fig. 2, pg. 3).
3. Mount unit in desired location. Mark and drill holes that line up with the top and bottom holes of the enclosure flange.
Secure enclosure with appropriate fasteners (Fig. 3, pg. 3).
4. Mount back plane to enclosure with hardware.
5. To facilitate wire entry utilize weather tight NEMA 4 rated connectors, bushings and cable.
6. Connect unswitched AC power (277VAC/60 Hz) to terminals marked [L, G, N]
(Fig. 1, pg. 2). Use 14 AWG or larger for all power connections (Output, AC Input).
7. LEDs will illuminate indicating each output is powered (Fig. 1, pg. 2).
8. Measure output voltage on terminals marked [COM, 24V, 28V] before connecting devices (Fig. 1, pg. 2).
This helps avoid potential damage.
9. For 24VAC output connect devices to terminals marked [COM, 24V] (Fig. 1, pg. 2).
For 28VAC output connect devices to terminals marked [COM, 28V] (Fig. 1, pg. 2).
10. Upon completion of wiring, secure enclosure door with latches and optional lock.
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.

Terminal and LED Identification Chart:

Output
LED
Terminals
COM & 24V 24VAC
COM & 28V 28VAC
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated "DANGEROUS VOLTAGE" within the products enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 1 -
WayPoint-307A - AC Outdoor Power Supply

Installation Instructions:

ON
Normal operating condition.
CAUTION: To reduce the risk of electric shock do not open enclosure. There are
no user serviceable parts inside. Refer servicing to qualified service personnel.

Overview:

Specifications:

• Individual power output LED indicators.
• Spare fuses included.
• NEMA 4/4X, IP66-11 Rated Outdoor Enclosure.
• Operating Ambient Temperature: -20º C to 50º C.
Enclosure Dimensions (H x W x D):
13.31" (338.074mm) x 11.31" (287.274mm) x
5.59" (141.986mm)
LED Status
OFF
No AC output. Blown fuse, AC failure.
Rev. 080911
WayPoint-307A
