WPTV244UL Series
CCTV Outdoor Power Supplies
Installation Guide
Models Include:
• WPTV244175UL
- 24VAC @ 7A (175VA)
or 28VAC @ 6.25A (175VA).
- Four (4) Protected Outputs.
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
• WPTV244300UL
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Four (4) Protected Outputs.
Rev. 021104
Advertisement
Table of Contents
Related Manuals for Altronix WPTV244UL Series
Summary of Contents for Altronix WPTV244UL Series
- Page 1 WPTV244UL Series CCTV Outdoor Power Supplies Installation Guide Models Include: • WPTV244175UL • WPTV244300UL - 24VAC @ 7A (175VA) - 24VAC @ 12.5A (300VA) or 28VAC @ 6.25A (175VA). or 28VAC @ 10A (280VA). - Four (4) Protected Outputs. - Four (4) Protected Outputs.
- Page 2 Overview: WPTV244UL Series outdoor CCTV Power Supplies provide power via four (4) protected outputs for CCTV Cameras, heaters, and other video accessories. Units are UL Listed UL2044 “U.S. and Canada for CCTV Equipment.” Four (4) Output WPTV Reference Chart: Protected...
- Page 3 CAUTION: Equipment to be installed/serviced by authorized/trained personnel only. Shut branch circuit power before installing/servicing equipment. WARNING: This installation should be made by qualified service personnel. Unit should be installed in accordance with the National Electrical Codes and all local codes. For continued protection against risk of fire replace all fuses only with the same type and rating (10A/250V for WPTV244175UL or 15A/32V for WPTV244300UL).
- Page 4 Fig. 1 Left Panel Right Panel Suggested Locations for Wire Entries Suggested Locations for Wire Entries Bottom Panel - 4 - WPTV244ULseries Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 5 Fig. 2 WPTV244175UL Fig. 2a Fig. 2b POWER DISTRIBUTING UNIT INPUT non-power limited Illuminated Power Disconnect Circuit Breaker with manual reset Black Lead White Lead XFMR Green Lead (ground) Terminal Blocks for Fig. 2 Power Distribution Board Terminals: Input from Input from transformer.
- Page 6 Fig. 3 WPTV244300UL Fig. 3a POWER DISTRIBUTING UNIT INPUT non-power limited Fig. 3b 115VAC Input 50/60 Hz. Illuminated Power Disconnect XFMR* Circuit Breaker with manual reset Green Lead (Ground) Terminal Blocks for Fig. 3 Power Distribution Board Terminals: Input from Input from transformer.
- Page 7 This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is in tended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included).
- Page 8 CARBON STEEL SHEET 4.21” 107mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. MEMBER II1WPTV244UL Series E20P - 8 -...
