WayPoint30A Series
AC Outdoor Power Supplies
Models Include:
WayPoint30AU
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Two (2) fuse protected outputs.
WayPoint30A4U
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Four (4) fuse protected outputs.
WayPoint30A8U
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Eight (8) fuse protected outputs.
Installation Guide
Rev. 091514-30A
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
WayPoint30ADU
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Two (2) Class 2 Rated PTC protected
power-limited outputs.
WayPoint30A4DU
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Four (4) Class 2 Rated PTC protected
power-limited outputs.
WayPoint30A8DU
- 24VAC @ 12.5A and/or 28VAC @ 10A.
- Eight (8) Class 2 Rated PTC protected
power-limited outputs.
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix WayPoint30A Series
Summary of Contents for Altronix WayPoint30A Series
- Page 1 WayPoint30A Series AC Outdoor Power Supplies Models Include: WayPoint30AU WayPoint30ADU - 24VAC @ 12.5A and/or 28VAC @ 10A. - 24VAC @ 12.5A and/or 28VAC @ 10A. - Two (2) fuse protected outputs. - Two (2) Class 2 Rated PTC protected power-limited outputs.
-
Page 2: Specifications
Overview: Altronix WayPoint Outdoor Power Supplies provide 24VAC and/or 28VAC distributed via two (2), four (4) or eight (8) outputs for powering CCTV cameras, heaters, and other video accessories. WayPoint30A Series AC Reference Chart: Input Current Total Number Class 2 Rated... -
Page 3: Installation Instructions
WARNING: When installing in a non-restricted service area use lock or other fastened means on door latches. This installation should be made by qualified service personnel and should conform to all local codes and in accordance with the National Electrical Code. WayPoint30A Series Installation Guide - 3 -... -
Page 4: Technical Specifications
Equipment to be Installed Outdoors (UL 60950-22). European Conformity. For fuse protected models: Replace blade type fuses with ratings from 3A up to 10A. WayPoint30AU and WayPoint30A4U incorporates 10A fuses. WayPoint30A8U incorporates 5A fuses. - 4 - WayPoint30A Series Installation Guide... -
Page 5: Caution High Voltage
COM 24V COM 24V BROOKLYN, NY 11220 Ground CAUTION HIGH VOLTAGE Circuit board incorporated in WayPoint30ADU (PTCs) Input Voltage Power Input PD2WP ALTRONIX CORP. www.altronix.com COM 24V COM 24V BROOKLYN, NY 11220 WayPoint30A Series Installation Guide - 5 -... - Page 6 Fig. 3 - WayPoint30A4U (Fuses) XFMR* RESET ALTRONIX CORP. www.altronix.com PD4WP BROOKLYN,NY 11220 Ground CAUTION HIGH VOLTAGE Circuit board incorporated in WayPoint30A4DU (PTCs) 5A 32V Fuses F1-F8 RESET ALTRONIX CORP. www.altronix.com PD4WPCB BROOKLYN,NY 11220 - 6 - WayPoint30A Series Installation Guide...
- Page 7 Fig. 4 - WayPoint30A8U (Fuses) XFMR* RESET ALTRONIX CORP. www.altronix.com PD8WP Common BROOKLYN,NY 11220 Ground CAUTION HIGH VOLTAGE Circuit board incorporated in WayPoint30A8D (PTCs) RESET ALTRONIX CORP. www.altronix.com Common PD8WPCB BROOKLYN,NY 11220 WayPoint30A Series Installation Guide - 7 -...
-
Page 8: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 outdoor pole mount kit is designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP3 and WP4 NEMA rated enclosures. PMK1 can be mounted on 2” to 8”... - Page 9 (servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. WayPoint30A Series Installation Guide - 9 -...
- Page 10 Notes: - 10 - WayPoint30A Series Installation Guide...
- Page 11 Notes: WayPoint30A Series Installation Guide - 11 -...
- Page 12 BRASS INSERT (X4) 10-32 X 0.25” (6.4mm) BRASS INSERT (X2) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
