- Page 1 WPTV244UL Series CCTV Outdoor Power Supplies Installation Guide Models Include: • WPTV244175UL • WPTV244300UL - 24VAC @ 7 amp (175VA) - 24VAC @ 12.5 amp (300VA) or 28VAC @ 6.25 amp (175VA). or 28VAC @ 10 amp (280VA). - Four (4) Protected Outputs.
-
Page 2: Specifications
Overview: These outdoor Altronix CCTV Power Supplies provide power via four (4) protected outputs for CCTV Cameras, heaters and other video accessories. Units are UL Listed UL2044 “U.S. and Canada for CCTV Equipment.” Four (4) Output WPTV Reference Chart: Altronix... -
Page 3: Terminal Identification
WARNING: This installation should be made by qualified service personnel. Unit should be installed in accordance with the National Electrical Codes and all local codes. For continued protection against risk of fire replace all fuses only with the same type and rating (15 amp/250V). Terminal Identification: PD4 - Power Distribution Module 1P - 3P... -
Page 4: Left Panel
Fig. 1 Left Panel Right Panel Suggested Locations for Wire Entries Suggested Locations for Wire Entries Bottom Panel - 4 -... - Page 5 Fig. 2 WPTV244175UL Fig. 2A 1P, 2P, 3P, 4P = FUSED OUTPUTS 1N, 2N, 3N, 4N = COMMON OUTPUTS POWER DISTRIBUTING UNIT INPUT non-power limited Power Switch 115VAC Input XFMR 50/60 Hz. Green Lead (Ground) Terminal Blocks for Fig. 2 1P, 2P, 3P, 4P = FUSED OUTPUTS Input from 1N, 2N, 3N, 4N = COMMON OUTPUTS...
- Page 6 Fig. 3 WPTV244300UL 1P, 2P, 3P, 4P = FUSED OUTPUTS 1N, 2N, 3N, 4N = COMMON OUTPUTS POWER DISTRIBUTING UNIT INPUT non-power limited Power Switch 115VAC Input 50/60 Hz. XFMR* Green Lead (Ground) Terminal Blocks for Fig. 3 1P, 2P, 3P, 4P = FUSED OUTPUTS Input from 1N, 2N, 3N, 4N = COMMON OUTPUTS transformer.
- Page 7 The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the presence of an insulated “DANGEROUS VOLTAGE” within the products enclosure that may be of sufficient magnitude to constitute an electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 8 11.25" 12" Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. II1WPTV244UL Series E05D MEMBER - 8 -...
