WPTV248UL Series
CCTV Outdoor Power Supplies
Installation Guide
Models Include:
WPTV248UL
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Eight (8) Fuse Protected Outputs.
WPTV248175UL
- 24VAC @ 7A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) Protected Outputs.
WPTV248300UL
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Eight (8) Protected Outputs.
Rev. 040506
WPTV248ULCB
- 24VAC @ 3.5A (85VA) or
28VAC @ 3A (85VA).
- Eight (8) PTC Protected Outputs.
WPTV248175ULCB
- 24VAC @ 7A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) PTC Protected Outputs.
WPTV248300ULCB
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Eight (8) PTC Protected Outputs.
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix WPTV248UL Series
Summary of Contents for Altronix WPTV248UL Series
-
Page 1: Installation Guide
WPTV248UL Series CCTV Outdoor Power Supplies Installation Guide Models Include: WPTV248UL WPTV248ULCB - 24VAC @ 3.5A (85VA) or - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). 28VAC @ 3A (85VA). - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs. -
Page 2: Specifications
Overview: WPTV248UL Series outdoor CCTV Power Supplies provide power via eight (8) fused or PTC protected outputs for CCTV Cameras, heaters, and other video accessories. Units are UL Listed UL 2044 “U.S. and Canada for CCTV Equipment.” Eight (8) Output WPTV Reference Chart:... -
Page 3: Installation Instructions
National Electrical Codes and all local codes. For continued protection against risk of fire replace all fuses only with the same type and rating (3.5A/250VAC). Terminal Identification: PD8 - Power Distribution Module Terminal Legend Function/Description 1P - 8P AC output. 1N - 8N AC output. WPTV248UL Series - 3 -... - Page 4 CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. Left Panel Right Panel Fig. 1 Suggested Locations for Wire Entries Suggested Locations for Wire Entries Bottom Panel - 4 - WPTV248UL Series...
- Page 5 2P & N through 8P & N for outputs 2 through 8) COMMON POWER OUTPUTS Class 1 Outputs Green Ground Wire Input 115VAC 50/60Hz Terminal Blocks for Fig. 2 24VAC or 28VAC fused or PTC protected outputs 1 through 8. WPTV248UL Series - 5 -...
- Page 6 COMMON POWER OUTPUTS 24VAC: Class 2 Not Wet/Class 3 Wet 28VAC: Class 1 Green Ground Wire Input 115VAC 50/60Hz Terminal Blocks for Fig. 3 24VAC or 28VAC fused or PTC protected outputs 1 through 8. - 6 - WPTV248UL Series...
- Page 7 COMMON POWER OUTPUTS Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset Green Ground Wire Input 115VAC 50/60Hz Terminal Blocks for Fig. 4 24VAC or 28VAC fused or PTC protected outputs 1 through 8. WPTV248UL Series - 7 -...
- Page 8 24VAC: Class 2 Not Wet/Class 3 Wet 28VAC: Class 1 Illuminated Power Disconnect Circuit Breaker with manual reset Green Ground Wire Input 115VAC 50/60Hz Terminal Blocks for Fig. 5 24VAC or 28VAC fused or PTC protected outputs 1 through 8. - 8 - WPTV248UL Series...
- Page 9 COMMON POWER OUTPUTS Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset Input 115VAC 50/60Hz Green Ground Wire Terminal Blocks for Fig. 6 24VAC or 28VAC fused or PTC protected outputs 1 through 8. - 9 - WPTV248UL Series...
- Page 10 24VAC: Class 2 Not Wet/Class 3 Wet 28VAC: Class 1 Illuminated Power Disconnect Circuit Breaker with manual reset Input 115VAC 50/60Hz Green Ground Wire Terminal Blocks for Fig. 7 24VAC or 28VAC fused or PTC protected outputs 1 through 8. - 10 - WPTV248UL Series...
-
Page 11: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included). - Page 12 4.21” 107mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIWPTV248UL Series H24R...
