- Page 1 DC Outdoor Power Supply/Chargers Installation Guide Models Include: WayPoint102 - 12VDC @ 10A. WayPoint104 - 24VDC @ 10A. More than just power. Rev. 062818-WPF...
- Page 2 Overview: Altronix DC Outdoor Power Supply/Chargers provide 12VDC or 24VDC and are designed to be conveniently located where power is required. WayPoint DC Reference Chart: Altronix Model Number Waypoint102 12VDC 3.5A 5A/250V 15A/32V Waypoint104 24VDC 4.5A 6.3A/250V 15A/32V Specifications: Input: Visual Indicators: •...
- Page 3 – DC + WayPoint102: 12VDC @ 10A continuous output (Non power-limited output). (Fig. 1h, pg. 4) WayPoint104: 24VDC @ 10A continuous output (Non power-limited output). Trigger EOL Trigger inputs can be normally open, normally closed from an output circuit Supervised (power-limited input) (Fig.
- Page 4 Fig. 1 - eFlow Board configuration Battery Fuse Input Fuse BAT FAIL AC FAIL AC DELAY SHUTDOWN 1 min. enable TRIGGER EOL NC C NO NC C NO + AUX – 2 hr. disable SUPERVISED RESET Fig. 2 Suggested Locations for Wiring Inlets Bottom of Enclosure - 4 -...
- Page 5 Fig. 3 - WayPoint102 and WayPoint104 AC FAIL BAT FAIL AC DELAY SHUTDOWN 5A 250V 1 min. enable TRIGGER EOL NC C NO NC C NO + AUX – 2 hr. disable SUPERVISED RESET CAUTION HIGH VOLTAGE The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may...
- Page 6 Notes: - 6 - WayPoint DC...
- Page 7 This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included).
- Page 8 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIWayPoint DC Series...
