Parts Identification - Detecto MedVue MV2 Owner's Manual

Item Qty Part Number
1 1 5930-B126-08
2 1 593GR986
3 2 6021-2071
4 1 6021-1065
5 7 6021-2069
6 2 6021-6008
7 2 6024-0126
8 1 6560-1125
10 4 6610-2000
11 1 6610-5119
12 7 6680-0004
13 4 6680-0052
14 2 6680-0214
15 1 8555-0526-0A
16 1 8555-0528-08
17 1 8555-0529-08
18 1 8555-B461-0A
20 1 8555-B510-08
21 2 8555-C213-08
23 1 8555-D501-0A
24 1 8555-D502-08
1 MV2PWR
INSTALLED ON RIGHT END CAP (AS VIEWED FROM MV2 BACK)
NOT SHOWN
46

PARTS IDENTIFICATION

LABEL: ETL
SERIAL TAG ASSY
SCW FILLISTER. MACHINE-SCW 06-32X.250
SCW THUMB.... MACHINE-SCW 06-32X.375
SCW TRUSS HEAD SHEET METAL #6 X .50
SCW TRUSS HEAD SHEET-METAL #6 X.375
WASHER FLAT FOR 5/32" POP RIVET
ADHESIVE LOCTITE 290 THRD LCKR, WICKING
JACK SOCKET, 1 EA (NO WASHERS OR NUTS)
BATTERY HOLDER 6-C CELLS
WASHER LOCK INT TOOTH #6 TYPE A Z-PL
WASHER LOCK HELICAL #4 REG Z-PL
RIVET POP, BH AL 5/32 DIA x .126-.187 GR
BACK PANEL WELDMENT
FRONT PANEL
BATTERY COVER
CABLE: BATTERY
RUBBER BALL
END CAP
PCB ASS'Y MEDVUE CONTROLLER
KEYPAD : MEDVUE
OPTIONAL AC ADAPTER 110-240VAC/12VDC @ 1 AMP
8555-0530-0M Rev E MedVue MV2 Owner's
Description
