Product Specifications

Device

Name:
Model:
Standards/Approvals/Certifications:
Device Testing:
Dimensions:
Weight:
Ports:
SIM:
Chipset:
LED:
Power:
Web UI OS Support:

Environmental

Operating Temperature:
IP67 rating for water and dust ingress protection
Internal heating element for startup and operation in cold environments
NOTE:
The PoE injector is an indoor device and considered support equipment. It can operate at a maximum
temperature of 35°C (95°F).

Network Connectivity

5G NR mmW
5G NR Sub6
4G LTE CAT 22
4x4 MIMO mmW Bands / 800MHz Component Carrier Aggregation
4x4 MIMO Sub6 Bands / 400MHz Component Carrier Aggregation
* Certification schedules dependent on customer launch requirements.
† Data plan required. Coverage subject to network availability.
5G OUTDOOR CPE FW2010e USER GUIDE
5G Outdoor CPE FW20100
FW2010-1 (FCC, ISED)
FW2010-2 (CE)
FCC, GCF, PTCRB
CE/ISED/MIC/RCM-ACMA
Bluetooth SIG
WEEE, RoHS, REACH
200mm x 300mm x 90mm (7.9" x 11.8" x 3.5")
3.78 kg (8.336 lbs)
1 x 5Gbps Ethernet LAN Port
Dual SIM, 2 x 4FF Nano SIM Slots
Multi-carrier support with automatic switching
Qualcomm® Snapdragon™ SDX55
Power and Status
Power over Ethernet (PoE)
Windows 10 and later
MacOS 10.14 and later
Linux® Ubuntu 18.04 LTS and later
-20°C to 60°C (-4 to 140°F)
*
51
