Indicator LED

There is a multifunction LED located on the FW2010e device in the SIM compartment (visible through
the protective shield). It changes colors and either blinks or glows solid to communicate current states
for the device.
LED Color
Blue
Green
Yellow
Red
5G OUTDOOR CPE FW2010e USER GUIDE
Operation Meaning
Solid Strong 5G connection (3 – 5 bars)
Blinking Weak 5G connection (1 – 2 bars)
Solid Strong 4G connection (3 – 5 bars)
Blinking Weak 4G connection (1 – 2 bars)
Solid Software update is in progress
Solid CPE is booting up, acquiring signal
Blinking No service, SIM error, or locked SIM card
