Side Menu

The Home page and each subscreen in the FW2010e Web User Interface includes a menu on the left,
which you can use to return to the Home page or jump to other pages. The current page is indicated
by a blue bar. A similar side menu is available when configuring devices with Inseego Connect.

Header Icons

The top of each FW2010e Admin Web UI page displays status indicators and icons.
Header Icon
LAN (Blue)
LAN (Black)
LAN (Grayed Out)
Network Signal Strength
SIM (Blue)
SIM (Black with Checkmark)
SIM (Grayed Out)

Getting Help

Select the question mark (?) in the upper right-hand corner of a page to go to the Customer Support
page where you can access this User Guide and other information for the FW2010e.
5G OUTDOOR CPE FW2010e USER GUIDE
Description
Routed
Available/Online
Disabled/Offline/No Physical Connection
Network Signal Strength Indicator. More bars
indicate more signal strength.
Routed
Available/Online
Disabled/Offline/No SIM
