© Elcom, s. r. o.
Figure 2.4 >>
Touch sensitive cashier
display.
Figure 2.5
Optional customer display.
Figure 2.6
Example barcode reader
(scanner).
Figure 2.7 >>
SRAM/Flash memory
modules.
12
The cash drawer is connected to the main unit by a thin cable that enables automatic opening.
The cable/connector combination allows for simple disconnection and movement. The cash
drawer supplied can also be opened manually using the removable key. There is a removable
coin tray and double clips on the note compartment.
Cashier display
A 640 × 480 VGA DSTN touch sensitive display is supplied
with the POS-4000 allowing a substantial amount of infor-
mation to be shown on the screen.
Optional external customer display
>
ment wear and tear caused by frequent plugging and unplugging of the network cable.
Ask your authorised POS-4000 dealer for more information and potential activation of the
infrared interface.
Barcode readers
>
interface and standard Canon connector. The unit supplies the scanner with +5 V of input vol-
tage. Both scanner and the POS-4000 should be properly programmed prior to connecting
one to each another.
SRAM and Flash memory expansions
The design of the POS-4000 facilitates simple memory
expansion by just replacing the SRAM memory module
with a module of greater capacity or by in-
stalling additional SRAM modules.
Only an authorised service techni-
cian should perform the exchange of
memory modules.
Communication adapter
The POS-4000 is able to communicate with a PC via modem, standard or wireless network if
equipped with proper PCMCIA devices. Wireless networking has its advantages in its speed,
POS–4000
An external customer display is a supplement to the internal custo-
mer display that is built into the body of POS-4000. The external
display is placed so that its digits are clearly visible to the customer
allowing more detail and more impact as well as flexibility of posi-
tioning.
IrDA
Infrared interface (IrDA) is convenient if data is frequently transfer-
red between the unit and a PC and neither the unit nor the PC is
connected to common computer network. This can save on equip-
The POS-4000 cash register is equipped with an interface for connec-
ting the barcode reader (scanner) by default. The POS-4000 is sup-
plied with an 8150 barcode reader with a stand for easy positioning.
Omni directional scanners are available at additional cost.
The scanner is connected to the unit using the built-in RS-232 serial
POS description
