Figure 2.12 >>
PC keyboard layout for
POS-4000.
Figure 2.13 >>
Touch sensitive cashier
display.
16
The Check key is used to mark the finished sale when finished by a cheque pay-
ment.
The key marked with Internet Explorer logo opens the window of the Internet
browser.
The Total key is used to finish the sale and also to mark the finished sale
when closed by a cash payment.

PC keyboard

A PC keyboard can also be connected externally to the POS-4000. Sale and registration is
analogous to the POS keyboard. The keys that cannot be re-programmed are the same as
in the EK-3000: Esc, Enter, Tab, Space, Shift+Tab and arrow keys. All other keys are
programmable.
It is recommended to programme the direct PLU and predefined surcharge/discount keys as
Shift+character key combination.
The following convenient keyboard shortcuts are provided by the PC keyboard:
Ctrl+F2
Ctrl+Alt+'
Shift+key
Ctrl+key
Ctrl+Shift+key

Description of displays

Cashier display description

The POS-4000 cashier display is a touch sensitive colour
LCD display of cutting-edge construction. It is capable of
displaying any character or icon and activating its assigned
function by pressing lightly using the supplied stylus or in-
dex finger.
The touch sensitive display is a very delicate device. Protect
the display from any mechanical damage and do not use the
display in humid environments.
POS–4000
– Toggling of
monitor,LCD+monitor).Chosen mode will initialise after
the ECR is turned on.
– Touch sensitive display calibration
– Character placed on top right part of a key
– Character placed on bottom left part of a key
– Character placed on top left part of a key
POS description
the graphic modes (LCD,
