Figure 2.15
Individual visual elements
of MS Windows CE envi-
ronment.
Figure 2.16
Error message dialogue
(left) and query dialogue
(right).
18
right side. When pressing the square, the menu unfolds and the visible unfolded options are
selected by pressing on. Use up and down arrow keys to browse through its options.

Tabs

The tabs are usually employed to increase informational capacity in a single window. Swit-
ching between tabs is much quicker than constantly entering and leaving windows.

Dialogue

Dialogue is the displayed view of interrelated checkboxes, buttons, labels, icons, or text rows
carrying out one function.
>

Error messages, queries

If an incorrect value or input was detected, an error message is displayed along with a brief
error description. Read the message carefully and press OK. The error message will disappear
and allow you to correct the problem.
Query is the dialogue that appears if an important operation is about to take place and con-
firmation is required such as deleting a PLU item. Accidental errors are thus minimised. Use
the OK key to confirm the operation (Ok Enter on POS keyboard, NumEnter on the
PC keyboard) and use the Cancel key to cancel the action (Cancel Esc on POS keyboard
and Esc on the PC keyboard).
>

Inserting the paper tapes into the printer

The POS-4000 cash register requires 2.1" (54 mm) thermal paper tapes for its operation. One
(on the left) is used for printing receipts and the other (right one) is used to print the hard
copy journal. Use only quality reels up to 2.4" (60 mm) in diameter as recommended from
Tate Fastforms.
POS–4000
POS description
