FLOW CHARACTERISTICS

The BLITZTAC portable monitor is designed for maximum flow of 500 GPM (2000 L/min) @ 175 PSI (12 BAR) and a maximum operating
pressure of 230 PSI (16 BAR) at lower flows. Do not exceed these limits.
4.1

AUTOMATIC, FIXED, AND SELECTABLE FLOW NOZZLES

A variety of water or foam nozzles may be used with the BLITZTAC portable monitor.
Automatic nozzles maintain a constant pressure by adjusting their opening to match the available flow. Consult the nozzle manufacturer
for maximum flow and pressure ratings. In all cases do not exceed 500 GPM (2000 LPM) @ 175 PSI (12 BAR) or 230 PSI (16 BAR).
See Section 3.3 on page 6.
4.2

STACKED TIPS OR SMOOTHBORE NOZZLES

NOZZLE
DIAMETER
FLOW
(GPM)
1-3/8" 251
1-1/2" 299
1-3/4" 407
NOZZLE
DIAMETER
FLOW
(L/min)
35 mm 951
38 mm 1131
44 mm 1540
4.3

STREAM STRAIGHTENERS

Stream quality, especially with smooth bore nozzles, is generally improved with the use of a stream straightener. A stream straightener is
integrated into the exit of the monitor.
4.4

USE WITH FOAM

The monitor may be used with various foam nozzles and foam solutions. Refer to fire service training for the proper use of foam.
WARNING
WARNING
WARNING
©Copyright Task Force Tips LLC 2021
20 PSI 40 PSI
REACTION FLOW
(LBS) (GPM)
59 355
71 423
96 ---
1.3 BAR 2.6 BAR
REACTION FLOW
(KG) (L/min)
27 1344
32 1600
44 ---
FLOW EXCEEDS RATING OF BLITZTAC PORTABLE MONITOR
---
For Class B fires, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Follow procedures established by the AHJ
for the specific fuel and conditions.
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer's instructions and fire service training as directed by the
AHJ.
Use of compressed air foam (CAF) with portable monitors can cause sudden surges in nozzle
reaction force resulting in risk of injury or death from hose whipping or an out of control monitor.
Be prepared for sudden changes in nozzle reaction caused by:
• Slug loading (Loss of foam concentrate sends slugs of air and water into the nozzle)
• Sudden release of built-up pressure in the hose when opening a nozzle
NOZZLE INLET PRESSURE
60 PSI
REACTION FLOW REACTION
(LBS) (GPM) (LBS)
119 435 178
141 --- ---
--- --- ---
NOZZLE INLET PRESSURE
3.8 BAR
REACTION FLOW REACTION
(KG) (L/min) (KG)
54 1646 81
64 --- ---
--- --- ---
Table 4.2
9
80 PSI 100 PSI
FLOW REACTION FLOW
(GPM) (LBS) (GPM)
500 236 ---
--- --- ---
--- --- ---
5.1 BAR 6.4 BAR
FLOW REACTION FLOW
(L/min) (KG) (L/min)
1893 108 ---
--- --- ---
--- --- ---
