6.3
ANCHORING BY HOOKING LEGS
The legs on the BLITZTAC portable monitor point back slightly so they can act as a hook for anchoring on posts, walls, door frames or
other fixed objects. Sliding can occur if the legs are unhooked due to the influence of the hose, nozzle, or operator.
GOOD
Nozzle reaction keeps leg hooked.
Object is close to hose.
Nozzle reaction keeps leg hooked.
Hose hits wall and helps hold position.
©Copyright Task Force Tips LLC 2021
Anchoring by Hooking to a Post
Anchoring by Hooking to a Wall or Door Frame
GOOD
Figure 6.3A
Nozzle reaction tends to
Figure 6.3B
12
POOR
Nozzle reaction tends to
unhook the leg.
POOR
unhook the leg.
LIX-750 March 11, 2021 Rev00
