8.0 RECOMMENDED PARK POSITION

For truck mounted applications it is recommended that the monitor be parked in a position such that the monitor's nozzle rests
against a bracket or support surface. If a support surface is not available, run the elevation against one of its travel stops to take some
of the backlash out of the gear drive. This will minimize bouncing of the nozzle when the apparatus is traveling. Always be sure the
monitor is properly parked before moving the truck and know the overall height to avoid damage from overhead obstructions such
as doors or bridges.
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) for information on programming DEPLOY,
OSCILLATE and PARK position Tornado RC models.

8.1 OVERRIDE KNOBS

In the event of electrical system failure on the monitor or fi re truck
the Tornado RC Monitor is factory supplied with knobs so the
monitor may be manually operated. To make the Tornado RC more
compact the manual override knobs may be removed. The drive
shafts have a hex so an 11/16" wrench or socket may be used for
manual override. The wrenching hexes are shown in fi gure 8.1.

9.0 FLOW CHARACTERISTICS

9.1 STACKED TIPS FLOW

NOZZLE
DIAMETER
1.0 INCH
1-1/4 INCH
1-1/2 INCH
NOZZLE
DIAMETER
25 MM
32 MM
38 MM
©Copyright Task Force Tips LLC 2008-2019
Wrenching Hexes on Drive Shafts
50 PSI 80 PSI
FLOW REACTION FLOW REACTION
(GPM) (LBS) (GPM)
210 80 270
330 120 410
470 170 —
FLOW EXCEEDS RATING OF TORNADO MONITOR
4 BAR 6 BAR
FLOW REACTION FLOW REACTION
(l/min) (KG) (l/min)
830 40 1000
1300 70 1700
1900 90 —
FLOW EXCEEDS RATING OF TORNADO MONITOR
Stacked Tips Flow Table
Fig 8.1
NOZZLE INLET PRESSURE
100 PSI
FLOW REACTION
(LBS) (GPM) (LBS)
120 300 150
190 460 230
— — —
NOZZLE INLET PRESSURE
8 BAR
FLOW REACTION
(KG) (l/min) (KG)
60 1200 80
100 1900 130
— — —
Fig. 9.1
16
11/16" (18mm) HEX
150 PSI 175 PSI
FLOW REACTION FLOW REACTION
(GPM) (LBS) (GPM)
360 230 390
— — —
— — —
10 BAR 12 BAR
FLOW REACTION FLOW REACTION
(l/min) (KG) (l/min)
1300 100 1400
— — —
— — —
LIY-300 August 12, 2019 Rev17
(LBS)
260
—
—
(KG)
120
—
—
