Battery Fault/Overload occurred
Battery Replacement: steady light
Charger Failure: steady light
Button operation
Cold Start function
When the main power is disconnected from UPS, it is capable of starting with
battery power for users' needs. Simply start the UPS as the instruction below.
"On/Off/Test/Silence" button
Turn on the UPS
Switch on the Load

Press the "ON" button until a single "beep" alarm disappeared or the LED display

turns on.
Shut Down the UPS
Switch off the Load

Press the "OFF" button for 3 seconds during Line/Battery-mode.

(If applicable) To avoid electrical hazards, please turn off the internal/external

input breaker. Then, turn off any external battery breaker and wait till all fans
completely shut down.
Test
Press once to start self-test function during Line-Mode
Silence
Press once to enable/disable alarm buzzer during Battery-Mode
Green mode
The Green mode feature will enable UPS no-Load or light-load shutdown to
maintain power consumption and battery life. During battery mode, the UPS will shut
down approximately 4 min with no load/light load operating.
Green mode can also be enabled or disabled via monitoring software.
Green Mode Enable: Turn on UPS normally. Green mode activates in default.
Green Mode Disable: When turning on UPS, please keep holding the "ON" button until
a double "beep" occurred.

4.4 UPS Configuration

UPS Manual test
Manual tests for UPS or battery can be conducted from the UPS configuration as
well and are functional even when the UPS is not charging the battery.
Simple test: It's recommended to conduct a simple simulation test when.
1. The first use of UPS.
2. Adding new loads.
3. 6 months' regular check-up
Switch on the UPS and wait for the power indicator to light up, then unplug UPS to
simulate the main power failure.
Manual Battery Test: Press the "test" button once. UPS will automatically conduct
a self-test. Please note that the UPS will briefly switch to battery mode.
© All rights reserved. All trademarks are property of their respective owners.
Battery Fault(Red)
Overload: Rapid flash
The master button for UPS control, refer to Button Operation
Button Display
ON/OFF/TEST/Silence Button
6
Battery Level
Display battery remaining
During battery or charger
failure, the indicator will flash
along with the fault indicator
