INT-SF
Partition keypad
Firmware version 2.02
int-sf_en 07/20
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INT-SF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Satel INT-SF

Summary of Contents for Satel INT-SF

  • Page 1 INT-SF Partition keypad Firmware version 2.02 int-sf_en 07/20 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
  • Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.

  • Page 3: Table Of Contents

    CONTENTS Features ........................... 2 Installation ........................2 Address setting ......................4 Description of terminals ....................5 Configuring ........................5 Description of parameters and options ............... 5 Using ..........................8 LED indicators ......................8 Sound signaling ......................9 4.2.1 Beeps generated when operating ................ 9 4.2.2 Signaling events ....................

  • Page 4: Features

    INT-SF SATEL The INT-SF partition keypad: • allows the user to control one partition of the alarm system, • can control the access to a single door. The keypad is compatible with the INTEGRA / INTEGRA Plus alarm control panels.
  • Page 5 SATEL INT-SF The keypad is designed for indoor installation. The place of installation should be readily accessible to the system users. 1. Open the keypad enclosure (Fig. 2). The enclosure opening tool, shown in the illustration, is included in the keypad delivery set.

  • Page 6: Address Setting

    INT-SF SATEL 9. If the keypad is to supervise the door status, connect the detector supervising the door status to the IN and COM terminals. If the keypad is not to supervise the door status, connect the IN terminal to the COM terminal or, when configuring the keypad, set value 0 for the “Max.

  • Page 7: Description Of Terminals

    SATEL INT-SF 2.2 Description of terminals - power input CLK - clock (expander communication bus) DTA - data (expander communication bus) COM - common ground - door status input (NC) - relay output 3. Configuring The keypad settings you can configure using: •...
  • Page 8 INT-SF SATEL Names of parameters and options from the DLOADX program are used in this manual. Shown in square brackets at the description of a parameter or option is the name presented on the display of the LCD keypad. Name – individual name of the device (up to 16 characters).
  • Page 9 SATEL INT-SF Access if armed [Code * in arm] – if the option is enabled, the users can gain access (turn the relay output on) when the partition is armed. If the option is disabled, the users cannot gain access when the partition is armed. The option is available, if the “Code+* do not disarm”...

  • Page 10: Using

    INT-SF SATEL when there is a delay between entering the code and the sounds emitted after verification of the code by the control panel. CHIME [Chime zones] – if this option is enabled, the partition keypad will audibly signal violation of zones with “Chime in module” option enabled, belonging to the partition operated by means of the keypad.

  • Page 11: Sound Signaling

    SATEL INT-SF 4.2 Sound signaling 4.2.1 Beeps generated when operating The installer can disable the sound signaling or replace it with flashing of the keys backlight (see “Configuring”). 1 short beep – any number key is pressed or the code is used.

  • Page 12: Code]

    INT-SF SATEL If you use the code to arm / disarm the partition and the LEDs start flashing alternately, this will mean that the keypad is waiting for the code of the other user (arming / disarming using 2 codes).

  • Page 13: Silencing The Alarm At The Partition Keypad

    SATEL INT-SF panic alarm – press and hold down for about 3 seconds. The installer defines whether the audible or silent panic alarm will be triggered. 4.3.5 Silencing the alarm at the partition keypad Press any number key to silence the keypad sounder during an alarm condition for about 40 seconds.
